Programmable Environmental Test Chambers For Temperature And Humidity Test
Product Introduction
Environmental Test Chamber can test the performance of materials in various environments and testing the heat resistance, cold resistance, dry resistance and humidity resistance of various materials. Suitable for testing the quality of electronic, electrical appliances, mobile phones, communications, meters, vehicles, plastic products, metals, food, chemicals, building materials, medical, aerospace and other products
STANDARD FEATURES
|
Model |
HD-E702-150 |
|
Internal dimension (W*D*H) |
500*500*600mm |
|
External dimension (W*D*H) |
700*1080*1480mm |
|
Temperature range |
-40~+150℃ |
|
Temperature fluctuation |
±0.5℃ |
|
Temperature uniformity |
2℃ |
|
Humidity range |
20~98%RH (Refer Image below) |
|
Humidity fluctuation |
±2.5%RH |
|
Humidity uniformity |
3%RH |
|
Cooling speed |
1℃/min in average (without loading) |
|
Heating speed |
3℃/min in average (without loading) |
|
Internal chamber material |
|
|
External chamber material |
Stainless steel |
|
Cooling method |
Air cooling |
|
Controller |
LCD touch screen, programmable control temperature and humidity Can set different parameter for cyclic test |
|
Insulation material |
50mm high density rigid Polyurethane foam |
|
Heater |
Explosion-proof type SUS#304 stainless steel fins radiator pipe heater |
|
Compressor |
France Tecumseh compressor |
|
Lighting |
Heat resistance |
|
Temperature sensor |
PT-100 dry and wet bulb sensor |
|
Observation window |
Tempered glass |
|
Testing hole |
Diameter 50mm, for cable routing |
|
SUS#304 stainless steel, 2pcs |
|
|
Safety protection device |
Protection for leakage Over-temperature Compressor overvoltage and overload Heater short circuit Water shortage |
The above are the standard parameters of the machine, we accept user customization
CHAMBER DESIGN FEATURES
1. High performance and quiet operation (68 dBA)
2. Space-saving designed for flush installation to wall
3. Full thermal break around doorframe
4. One 50mm diameter cable port o left, with flexible silicone plug
5. Accurate wet/dry-bulb humidity measurement system for easy maintain
