HVS-1000Z Automatic Turret Digital Display Micro Vickers Hardness Tester From China

FOB Price

US$ 2,500 - 3,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KASON		Place of Origin	Shandong, China
Model Number	HVS-1000Z

HVS-1000Z Automatic Turret Digital Display Micro Vickers Hardness Tester from China

1.Applications:

HVS-1000Z Automatic Turret Digital Display Micro Vickers Hardness Tester with large screen LCD

display, automatic turret type, use the menu interface type structure, can choose hardness scale HV or

HK in the operation panel, the test hardness value will automatic calculation, automatic display.

For all kinds of hardness value can mutual conversion. You can fine-tuning modify the hardness values,

so that the hardness value meet the requirements more accurately.

Eyepiece Structure equiped with a digital encoder, measuring the D1, D2 values, the hardness values and

D1, D2 values will display on the LCD screen directly. The testing results will automatic storage, processing

and printing. With RS-232 interface, can connect with the computer.

During the test, the pressure head and the objective lens can be switch to each other automatically, and

the test points are automatic positioning precision.

2.Main Technical Specifications:

Model	HVS-1000Z
Test Force	10gf (0.098N),25gf (0.245N),50gf (0.49N), 100gf (0.98N), 200gf (1.96N),300gf (2.94N), 500gf(4.9N),1000gf (9.8N)
Standards	GB/T4340, ASTM E92
Min. Measuring Unit	0.031 µm
Data Output	LCD Screen Display, Built-in Printer, RS-232
Convert Rulers	Rockwell, Brinell
Hardness Measuring Range	8 ~ 2900 HV
Method Of Testing Force Applied	Automatic (Loading, Dwell, Unloading)
Turret Way	Automatic Turret
Test Microscope Magnification	400X (Measuring), 100X (Observation)
Duration Time	0 ~ 60 s
Max. Height Of Specimen	85 mm
Distance Of Indenter To Outer Wall	95 mm
X-Y Testing Table	Dimension:100100mm Max.Movement:2525mm
Power Supply	AC 220V, 50Hz

3.The Packing Way Of Our Export Machines:

4.The Realistic Pictures Of Our Factory:

5.Our Process Of Foreign Trade:

6.Our company can also produce the customized testing machines as clients' requirements.

You can contact me as the below information.
