2019 New NJS-50 50 N.m digital display torsion testing machine/torsion tester from China
Applications:
2015 New NJS-50 50 N.m digital display torsion testing machine/torsion tester price is mainly suitable for materials labs of scientific research dept., colleges or universities and industrial
enterprises to test the mechanical properties of materials under torsion condition.
features:
NJS series is used for the torsion test for all kinds of materials, by imposing a torque by manual.
There are two testing methods:
Automatic testing: Turn the hand wheel until the test rod breaks. The testing machine will automatically test
the yield torque M1 and the maximum torque M2.
Manual testing: choose the test angles and torques of any 9 points during the testing period and record them.
Able to retrieve or print latest testing results after the test.
Main Specifications:
Model |
NJS-50 |
NJS-100 |
NJS-150 |
NJS-200 |
Max torque(N/m) |
50 |
100 |
150 |
200 |
Min. reading of torque (N.m) |
0.1
|
|||
Max. reading of torsion angle( ° ) |
9999.9 |
|||
Min. reading of torsion angle ( ) |
0.1
|
|||
Torque value accuracy |
≤±1 |
|||
Relative error of torque indications |
≤ ±1.0% |
|||
|
Relative repeatability error of torque indications |
≤1.0% |
|||
Diameter of specimen (mm) |
10 |
|||
Max. testing space (mm) |
260
|
|||
Power |
AC 220V±10%,50Hz |
|||
