JBW-500B Computer Display Pendulum Impact Testing Machine Astm D3420

JBW-500B Computer Display Pendulum Impact Testing Machine astm d3420

1. Application

JBW-500B Computer Display Pendulum Impact Testing Machine astm d3420  are mainly used to determine the anti-impact capability of metal materials under dynamic load. Carry out the functions of zero clearing and automatic return, capturing the value of lost impact energy and pendulum  cycle  by  means  of  setting  up  with  computer  program,  and  the  results  can  be monitored,  stored  and  printed  out.  Control  box  or  computer  program  control  is  alternative operating method. JB-W series impact testers are adopted by many institutes and high-tech enterprises.

2. Standards:

ASTM  E23, ISO148-2006 and GB/T3038-2002, GB/229-2007.

3. Features:

3.1 Fully automatic, sample feeding, auto position the sample; high efficiency;

3.2 Pendulum rising, impact, sample feeding, position, free releasing is realized automatically by easy PC mouse click;

3.3 Safety pin guaranties the impact action, standard protection shell to avoid any accident.

3.4 Pendulum will automatically rising and ready for next impact action after specimen breakout.

3.5 With two pendulums (big and small), PC software to display the energy loss, impact tenacity, rising angle, test average value etc. test data and result, also the curve display available; with calculation and report printing function. The dial scale can show test results too.

4. Main Technical Specifications:

5. Standard Accessories

5.1 Main unit----------1 set

5.2 Pendulum

5.3 Span specimen plate (L = 40mm)----1 pc
5.4 Specimen centering plate (L = 40mm)(U, V)----1 pc
5.5 Stripping attachment----1 pc
5.6 Internal hexagonal wrench (S=30mm)---1 pc
5.7 Anchor bolts (M16x300mm)---4 pcs

5.8 Impact testing security guards----1 pc
5.9PC software & PC& Printer
