500kn 600kn Digital Display Hydraulic Universal Tensile Compression Bending Testing Machine Equipment
1. Application:
WE-600D 600KN Digital Display Hydraulic Tensile Strength Testing Machine adopts hydraulic loading,
digital display, easy and convenient to operate. It is mainly used to execute the tension, compression,
bending, flexural etc. test for metal materials. Attached with simple accessories and devices, it can be
used to test wood, concrete, cement, rubber, and so on.
It is very suitable for making test to different metal or nonmetal materials under high toughness and
hardness against extreme big loading force.
2.Standards:
ISO, ASTM, DIN, JIS, etc.
3.Main Specifications:
|
Model |
WE-600D |
|
Structure |
6 Column (Four Columns Two Ball Screws) |
|
Control Way |
Loading Process Manual Control |
|
Max. Load |
300 KN (30 TONS) |
|
Load Accuracy |
≤± 1% |
|
Load Range |
2%~100%FS (6KN~300KN) |
|
Load Resolution |
0.01 KN |
|
Piston Speed |
0-140mm/min Manual Adjustment |
|
Crossbeam Lifting Speed |
200mm/min |
|
Max. Tension Test Space |
650mm |
|
Max.Compression Test Space |
500mm |
|
Center Spacing Between Columns |
540mm |
|
Column Effective Spacing |
475mm |
|
Max. Piston Stroke |
250mm |
|
Clamping Method |
Manual Clamping |
|
Round Specimen Clamping Range |
Φ10-Φ20mm,Φ20-Φ32mm |
|
Flat Specimen Clamping Range |
0-15mm |
|
Flat Specimen Clamping Width |
80mm |
|
Compression Platen Size |
Φ 160mm |
|
Span Of Bending Rollers |
450mm |
|
Width Of Bending Rollers |
120mm |
|
Power Supply |
3-phase,AC380V, 50Hz (Can Be Customized) |
