WDW-600 600KN Metal Tensile Tester Price / Lab Testing Machine UTM
/ Tensile Testing Machine
1.Application:
It is applicable for wide range of material for tension, compression, bending, shearing and low cycle test.
Suitable for metal, rubber, plastic, spring, textile, and components testing.
It is widely used in the corresponding industries, research and development, test institutes and training
centers etc.
2.Standard:
ASTM, ISO, DIN, GB and other international standards.
3.Main Technical Parameters:
Model |
WDW-500 |
WDW-500E |
WDW-600 |
WDW-600E |
|
Max. Load |
500kN |
600kN |
|||
Load Accuracy |
1 class |
0.5 class |
1 class |
0.5 class |
|
Load Range |
2%-100%FS |
0.4%-100% FS |
2%-100%FS |
0.4%-100% FS |
|
Structure |
Four-column floor model (upper is compression and lower is tensile) |
||||
Control Method |
Computer control |
||||
Resolution |
1/300000 |
||||
Measuring Range Of Deformation |
0.2%-100%FS |
||||
Accuracy Indication Of Deformation |
≤±0.5% |
||||
Disp. Indicating Relative Error |
≤±1% |
||||
Displacement Resolution |
0.04um |
||||
|
Adjusting Range Of Control Rate Of Load |
0.005~5%FS/S |
||||
Adjusting Range Of Displacement Rate |
0.05-200mm/min (can be customized) |
||||
Tensile Space |
650mm (can be customized) |
||||
Compression Space |
650mm (can be customized) |
||||
Test Width |
650mm (can be customized) |
||||
Power Supply |
AC220/380V±10%, 50Hz (can be customized) |
||||
Grips |
Hydraulic automatic |
||||
4.Software Interface:
5.The Packing Way Of Our Export Machines:
6.The Realistic Pictures Of Our Factory:
7.Our Cooperative Partners:
8.Our company can also produce the customized testing machines as clients' requirements.
You can contact me as the below information.
