N9K-C93180YC-EX Overview
N9K-C93180YC-EX is one of the Cisco Nexus 9300-EX switches. Cisco Nexus 9300-EX platforms are the next generation of fixed Cisco Nexus 9000 Series Switches. The new platforms support cost-effective cloud-scale deployments, an increased number of endpoints, and cloud services with wire-rate security and telemetry. The platforms are built on modern system architecture designed to provide high performance and meet the evolving needs of highly scalable data centers and growing enterprises.
- N9K-C93180YC-EX Specification
-
N9K-C93180YC-EX Specification Ports
48 x 10/25-Gbps and 6 x 40/100-Gbps QSFP28 ports
Downlink supported speeds
1/10/25-Gbps speeds
CPU
4 cores
System memory
24 GB
SSD drive
64 GB
System buffer
40 MB
Management ports
2 ports: 1 RJ-45 and 1 SFP
USB ports
1
RS-232 serial ports
1
Power supplies (up to 2)
650W AC, 930W DC, or 1200W HVAC/HVDC
Typical power (AC/DC)
210W
Maximum power (AC/DC)
470W
Input voltage (AC)
100 to 240V
Input voltage
(high-voltage AC [HVAC])200 to 277V
Input voltage (DC)
–48 to –60V
Input voltage
(high-voltage DC [HVDC])–240 to –380V
Frequency (AC)
50 to 60 Hz
Fans
4
Airflow
Port-side intake and exhaust
Physical dimensions
(H x W x D)1.72 x 17.3 x 22.5 in.
(4.4 x 43.9 x 57.1 cm)Acoustics
48.5 dBA at 40% fan speed, 64.9 dBA at 70% fan speed, and 77.8 dBA at 100% fan speed
RoHS compliance
Yes
MTBF
390,330 hours
Maximum number of Longest Prefix Match (LPM) routes
896,000
Maximum number of IP host entries
896,000
Maximum number of MAC address entries
256,000
Maximum number of multicast routes
32,000
Number of Interior Gateway Management Protocol (IGMP) snooping groups
Shipping: 8,000
Maximum: 32,000
Maximum number of Cisco Nexus 2000 Series Fabric Extenders per switch
16
Maximum number of Access Control List (ACL) entries
Per slice of the forwarding engine:
4000 ingress
2000 egress
Total (2 forwarding slices):
8000 ingress
4000 egress
Maximum number of VLANs
3,967
Number of Virtual Routing and Forwarding (VRF) instances
Shipping: 1,000
Maximum: 16,000
Maximum number of ECMP paths
64
Maximum number of port channels
512
Maximum number of links in a port channel
32
Number of active SPAN sessions
4
Maximum number of VLAN’s in Rapid per-VLAN Spanning Tree (RPVST) instances
3,967
Maximum number of Hot-Standby Router Protocol (HSRP) groups
490
Number of Network Address Translation (NAT) entries
1,023
Maximum number of Multiple Spanning Tree (MST) instances
64
Flow-table size used for Cisco Tetration Analytics platform
64,000
Operating temperature
32 to 104°F (0 to 40°C)
Nonoperating (storage) temperature
–40 to 158°F (–40 to 70°C)
Humidity
5 to 95% (noncondensing)
Altitude
0 to 13,123 ft (0 to 4000m)
Weight (without power supplies or fans)
17.2 lb (7.8 kg)
