Description:
Thermocouple` wire is wire compensation for thermocouples and second (base) of the instrument signal transmission, to the elimination of thermocouple cold junction temperature measurement error caused by the change to ensure that the instrument on medium temperature measurement accuracy, applicable to the power, metallurgical, oil, chemical, textile and other industrial and national defense research departments automation Thermometer single point or multi-point connection.
Thermocouple wire technical indicators:
Model | Graduation | Equipped with thermocouple | Compensation wire alloy wires | ||
Cathode | Anode | Color | |||
BC BC | B B | PtRh30-PtRh6 | Cu | Cu | Follow standard:BS/ANSI/DIN/JISC
|
SC SC | S S | PtRh10- Pt | SPC (Cu) | SNC (Cu-Ni 0.6) | |
RC RC | R R | PtRh13- Pt | RPC (Cu) | RNC (Cu-Ni 0.6) | |
KCA KCA | K K | NiCr-NiSi | KPCA (Fe) | KNCA ((Cu-Ni 22) | |
KCB 1D | KPCB(Cu) | KNCB (Cu-Ni 40) | |||
KX KX | KPX(NiCr 10) | KNX (Ni-Si 3) | |||
NC NC | N N | NiCrSi- SiNi | NPC(Fe) NPC (railways) | NNC (CuNi 18) | |
NX NX | NPX (Ni-Cr-Si 14) | NNX (Ni-Si 4) | |||
EX EX | E E | SiNi-CuNi | EPX (NiCr-10) | Methylxanthine (Cu-Ni 45) | |
JX JX | J J | Fe-CuNi | JPX(Fe) | JNX (Cu-Ni 45) | |
TX TX | T T | Cu-CuNi | TPX(Cu) | TIPS (Cu-Ni 45) | |
WC3/25 | WRe3-WRe25 | WRe3- WRe25 | WPC3/25 WPC3/25 | WNC3/25 WNC3/25 | |
WC5/26 WC5/26 | WRe5-WRe26 | WRe5- WRe26 | WPC5/26 WPC5/26 | WNC5/26 WNC5/26 | |
Thermocouple wire Insulation detail:
Thermocouple Color standard:
Thermocouple wire/cable photo:
Order Guide:
1. Inquiry-Professional quotation. |
2. Confirm the price, lead time, artwork, payment term etc. |
3. Topright sales send the Proforma Invoice with Topright seal. |
4. Customer make the payment for deposit and send us Bank receipt. |
5.Initial Production Stage-Inform the clients that we have got the payment,And will make the products according to your request,. After getting the sample or drawing approval, we inform that we will arrange the production & inform the estimated time. |
6. If possible,middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again. |
7. End Production-Mass production products photos will send to you for approval. You can also arrange the third party Inspection . |
8. Clients make payment for balance and Topright Ship the goods .Also can accept payment term-Balance against B/L Copy Or L/C payment Term which we discussed. Inform the tracking number and check the status for clients. |
RAQ:
1. Why the price is so low?
You are ordering directly from the factory.
2.Where is your factory located? How can I visit there?
Our factory is located in Yancheng City, Jiangsu Province, China, about 4 hours bus ride from Shanghai .All our clients, from home or abroad, are warmly welcome to visit us.
3.What type of payment do you have available?
A:We accept TT and L/C,as sample order,the Western Union,Money gram and Aliexpress is available.
4.How can I get some samples?
We are honored to offer you samples.
5.How does your factory do regarding quality control?
"Quality is in my hand,customer in our heart”. Topright people always attach great importance to quality controlling from the very beginning to the very end.
Welcome to contact us for more details ,most competitive price for you!
..............run with you together!
