16mm Electric Enail Coil Heater With K Type Thermocouple

US$ 15 - 20 MOQ: 5 Sets
Key Specifications
Get Latest Price
Brand Name:
Topright
Place of Origin:
Jiangsu, China
Type:
Air Heater, Air Heater, spring & straight
Contact Supplier Request Quote Chat Now
Topright Industrial Technology Yancheng Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Topright
Place of Origin Jiangsu, China
Certification CE,SGS
Warranty 1 Year
Weight 0.15
Dimension(L*W*H) 15*10*15
Condition New
Voltage 220-380V
Power Source Electric

16mm Electric Enail Coil Heater with K Type Thermocouple

Product Description

Product description:

Hot runner heater’s production length in 200-3000mm is mainly used for hot runner mold or, as well as other precision heating system. Spring heating ring external using high quality Ni-Cr steel tube, the internal use of high purity magnesium oxide , high temperature resistance wire, and first-class manufacturing technology . The wire is after the annealed, with flexibility can be bent into an arc or circle heating. Its high working temperature, fast heating, uniform heating precision, long service life, can be automatically controlled area, high thermal conduction, while internal heating material damage, external can reuse.

ID20mm



Length 10.6/12.7m/13.3mm;



Voltage : 24/110/120/220v;



Wattage:100/150/250w



With TC K/J



With Kevlar sleeve



With PID Control



With Quartz Nail

16mm Electric Enail Coil Heater with K Type Thermocouple16mm Electric Enail Coil Heater with K Type Thermocouple

Name of product

Electric D-nail/Enail Heating unit

Inner Diameter of coiled heater

8/10/14/16/18/20mm  ( + 0.05mm)

Coil Height

13.3mm/12.7mm  ( + 0.05mm)

Flat Coil

ID9mm,OD26mm

ID10mm,OD27mm   ( + 0.05mm)

Voltage

12v;24v;120v;220v

Wattage

100w;120w;150w;250w

Cross-section

3x3mm;2.2x4.2mm

Thermocouple

K or  J type

Connector plug

Xlr female and male 5 pin

Sleeve  material

kevlar/fiberglass(Fashional)

Sleeve color

red,black,yellow,green,blue,and black with yellow strip

PID Temperature controller

L125xW90xH35mm

L130xW120xH70mm

More Fashion Nail Coil Heater In Topright Industrial:

16mm Electric Enail Coil Heater with K Type Thermocouple16mm Electric Enail Coil Heater with K Type Thermocouple

Application

APPLICATION:

1. Injection moulding machine nozzle



2. Hot Runner Nozzles & Bushings.



3. Packaging machineries



4. Hot runner Injection moulds.



5. Injection & Blow Moulding Machine Nozzles.



6. PET prefrom & Thin wall container Moulds



7. Hot runner Manifolds.

16mm Electric Enail Coil Heater with K Type Thermocouple

Packaging & Shipping

 16mm Electric Enail Coil Heater with K Type Thermocouple



Company Information

 Since 2001,Topright have been engaged in the development, design, production and sales in one of the sales of industrial technology company, according to the customer needs, provide tailored solution of design, committed to the electric heating and temperature measurement in the field of development. Topright's products have been exported to Europe, America, Asia,Mid East etc. more than 90 countries.  We supply different heating element for example silicone rubber heater, kapton heater, band heater, cartridge heater, tubular heater, thermocouple and ect. More details pls link online store:

16mm Electric Enail Coil Heater with K Type Thermocouple

How does your factory do regarding quality control?
"Quality is in my hand,customer in our heart”. Topright people always attach great importance to quality controlling from the very beginning to the very end.

Topright continuously strive to find ways of reducing our production costs, and passing the savings over to you.Superior quality, stylish designs, competitive price and perfect service won us honorable customers.Topright service includes regular and thorough inspections throughout the manufacturing process, eliminating the need to employ additional quality control inspectors.

16mm Electric Enail Coil Heater with K Type Thermocouple

16mm Electric Enail Coil Heater with K Type Thermocouple
