Home > Products > Infrared temperature sensor > 4-20mA infrared temperature sensor
4-20mA infrared temperature sensor
- 500 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
- K type infrared temperature sensor
- 0-100C No contact infrared temperature sensor infrared thermometertemperature sensor
- high quality cartridge electric heating tube
- Internal line cartridge electric heating tube
- 12v 220v 200w high density high temperature electric cartridge heater
- cartridge electric heating tube with accessories
Product Details
Brand Name: | OEM | Place of Origin: | Jiangsu, China | Model Number: | IRI-08A |
Temperature Range: | 0-300C | Usage: | Industrial | Theory: | Infrared Thermometer |
Accuracy: | 0.1 |
Product Description
Features
Infrared temperature sensors are integrated. Sensors, optical systems and electronic circuit cluster in the stainless shells; it is easy for installation, the standard screw on the stainless steel shells can be quickly connected with the parts installed. In addition, it also has different models of selected parts (e.g. blow protective housings, 90-degree adjustable installation supports, 3-dimension adjustable installation supports, special purpose digital control instruments, etc) to meet different requirements.
Specifications
Basic performance | Protection | IP65(NEMA-4) |
Ambient temperature | 0 ~ 60°C | |
Storage temperature | -20 ~ 80°C | |
Relative humidity | 10-95% (NO dews) | |
Material | Stainless steel | |
Size | 106mm * Φ20mm (length * diameter) | |
Cable length | 1m (standard), 3m, 15m and particular specifications (customized) | |
Electric parameters | Operating power | 24V DC |
Max current | 20mA | |
Output signals | 0-5V linear, 10mV/°C | |
Measurement parameters | Spectrum range | 8 ~14 μm |
Temperature range | 0 ~ 500 °C | |
Optical resolution | 15:1 | |
Adapting time | 300ms (95%) | |
Measurement Accuracy | ±1% or ±1.5°C% of the measuring value, and the maximum value (environment temperature: 23°C±5) | |
Repeated accuracy | ±0.5% or ±1°C% of the measuring value, and the maximum value (environment temperature: 23°C±5) | |
Launch rate | 0.95 fixed (coordinates with special purpose digital display controllers to be able to modify online launch rates) |
Product Photos
