Pull Force Measuring Instrument Push Pull Dynamometer Toy Torque Tester
Application:
SH Portable force mesuring tools; Its own characters, with facility, high resolution,which can be used not only for simple measurement of tension and compression force but also used for various test purposes; such as switch testing, connector insertion/withdraw test, and fracture test, is efficient push pull testing equipment in a new generation.
Feature:
Comparing function: Initial input of the tolerance limit(Max/Min)enables the device to judge the measured result as Go(Green pilot lamp)/NG(Red pilot lamp);
Peak holding and auto-releasing function: Catching and holding the peak value in test, the peak holding time can be set(1-10 seconds);
LCD screen direction turning function:Pressing the unit key for 3 seconds, LCD screen will change its direction;
RS-232C output: Transmitting the data to Printer or computer, saving it into "Excel" for analysis or printing;
Automatic power off function: Power off time (1-60minutes) can be set by yourself;
Memory function: Memory 10 testing data, and calculate the average;
Units conversion: Converting three units(N, kgf, ibf) automatically.
Key specification
Model |
SH-2 |
SH-5 |
SH-10 |
SH-20 |
SH-50 |
SH-100 |
SH-200 |
SH-500 |
Capacity |
2N |
5N |
10N |
20N |
50N |
100N |
200N |
500N |
Load Resolution |
0.001N |
0.001N |
0.005N |
0.01N |
0.01N |
0.05N |
0.1N |
0.1N |
Sensor conformation |
Sensor Inside |
|||||||
Measuring range |
10% ~100% FS |
|||||||
Inaccuracy |
± 0.5% |
|||||||
Power |
8.4V 1.2V × 7( Nickel hydride battery ) |
|||||||
Charging time |
About 4 hours |
|||||||
Operating time |
About 40 hours |
|||||||
Waiting time |
About 3 months |
|||||||
Battery life |
||||||||
Adaptor |
Input : AC 220V 50Hz Output : DC 12V 300mA |
|||||||
Weight |
About 0.7kg |
|||||||
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days. Please be aware that our
production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by GESTRE Instruments Co Ltd. Besides,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team
will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product
use training, each of our product provide video training to show you how to install & operate. We can arrange engineer
to train the operation of equipment to customer’s company when you need. Main clients : SGS, BV and Intertek. Our
products are widely recognized and trusted by users.
♥ More information welcome to contact us now!
And welcome to our company! We display more new design in our showroom.
