Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > Automatic UV Lacquer Coating Machine
US$ 15,300 - 15,600
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Vinovo
Place of Origin:
Zhejiang, China
Model Number:
SGUV-480A
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Paper Extrusion Coating Laminating MachineUS$ 22,500 - 22,800MOQ: 1 Set -
Automatic UV Fabric Pvc Coating MachineUS$ 15,300 - 15,600MOQ: 1 Set
-
Automatic UV Doctor Blade Coating MachineUS$ 8,700 - 9,000MOQ: 1 Set
-
Automatic UV Silicone Coating MachineUS$ 15,300 - 15,600MOQ: 1 Set
-
YGFM-1100A Fully Automatic Flatbed Laminator LaminatorUS$ 50,100 - 50,400MOQ: 1 Set
Brand Name
Vinovo
Place of Origin
Zhejiang, China
Model Number
SGUV-480A
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Weight
1000kg
Dimension(L*W*H)
3000*850*1100mm
Voltage
220/380V
Power
10.7kw, 107kw
Application
Machinery & Hardware
Condition
New
Automatic Grade
Automatic
Driven Type
Electric
Packaging Material
Plastic
Packaging Type
Film
Automatic UV lacquer coating machine
Product Description
Features
- Before configuring the suction paper feeding machine and automatic closing machine;
- Equipped with UV curing or IR drying device;
- Roll coating variable speed control;
- Single-handle roller adjustments;
- Air-suction sheets hold-down throughout conveyor paper path;
- Ultra compact footprint;
- Easy access UV lamp replacement;
- High velocity blower fan for cooling and exhaust;
- Safety locker on all machine doors and covers;
- Full coverage protection against UV radiation around the UV lamp chamber;
- Lower temperature control on the UV lamp chamber surface;
- Interlocks design prevent against misoperation;
- Single phase power supply 1Φ-220V-50/60Hz.
Parameters
Model | SGUV-480A |
Max sheet size | 450*650mm |
Min sheet size | 150*210mm |
Sheet weight | 150-500g/m2 |
Speed | 0-25m/min |
Power | 10.7kw |
UV lamp | 1pcs*4.0kw |
IR lamp | 3pcs*0.9kw |
Weight | 1000kg |
Dimension | 3000*850*1100mm |
Warranty | 1 Year |
Samples
Certifications
Our Services
Quality guarantee&Service
1. Each machine is manufactured by professional experienced staff.
2. Production process is under strict supervision and adopts China and world toppest production engineering.
3. The warranty time is one year. Quick-wear part is excluded.
4. When warranty date expires, lifetime maintenance service is provided.
5. We can also offer PVC, PE films, BOPP films, stamping dies, hot foil papers etc.
Price governs while the quality is the same.
Service governs while the price equals.
T&D MACHINERY promise to offer perfect after-sale service!
Company Information
FAQ
Q: What is the machine size after packaged?
A: 3000*850*1100mm
Q: Degree of automation ?
A: Automatic
Q:Heating way , electric heating or oil heating?
A: Oil heating
Q: How to receive the paper,automatic stacker or jogger delivery?
A: Jogger delivery
Q: How to install the machine?
A: Sent the install machine video to you.
Q: How to set the paper size?
A: By the touch screen.
