Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > Sublimation Coating Machine for Mugs
US$ 8,700 - 9,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Vinovo
Place of Origin:
Zhejiang, China
Model Number:
SGUV-660
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Pearl Beads Coating MachineUS$ 8,100 - 8,400MOQ: 1 Set -
SGUV-1000B UV Opc Drum Coating MachineUS$ 21,150 - 21,450MOQ: 1 Set
-
SGUV-1000C UV Spot uv Coating MachineUS$ 18,900 - 19,200MOQ: 1 Set
-
SGUV-1200C UV Wax Coating MachineUS$ 21,300 - 21,600MOQ: 1 Set
-
YFMA-520 Automatic Vacuum Paper Film Laminating Machine PriceUS$ 25,000 - 28,500MOQ: 1 Set
Brand Name
Vinovo
Place of Origin
Zhejiang, China
Model Number
SGUV-660
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Weight
850kg
Dimension(L*W*H)
3250*1180*1230mm
Voltage
220/380V
Power
12kw, 12kw
Application
Machinery & Hardware
Condition
New
Driven Type
Electric
Packaging Material
Plastic
Packaging Type
Film
sublimation coating machine for mugs
Product Description
Features
- This UV Coating Machine is equipped with UV curing and IR drying device;
- Digital frequency converter speed control. And independent conveyor driven;
- Larger diameter coating rollers makes the coating effect smoother & brighter;
- Full coverage splash guards to protect from splashing;
- Used vacuum airbed for maximum hold down the paper sheets on conveying;
- UV magnetic leakage transformer with parallel capacitor design can better endure the voltage fluctuating impact;
- Two level UV lamp power setting;
- Easy access UV lamp chamber and replacement;
- High velocity blower fan for cooling and exhaust;
- Safety locker on all machine doors and covers;
- Full coverage protection against UV radiation around the UV lamp chamber;
- Lower temperature control on the UV lamp chamber surface;
- Emergency stop switches at arms length throughout the machine;
- Interlocks design prevents against misoperation.
Parameters
Model | SGUV-660 |
Max sheet size | 630*915mm |
Min sheet size | 150*210mm |
Sheet weight | 150-500g/m2 |
Speed | 0-40m/min |
Power | 12kw |
UV lamp | 1pcs*6.5kw |
IR lamp | 3pcs*1.2kw |
Weight | 850kg |
Dimension | 3250*1180*1230mm |
Warranty | 1 Year |
Samples
Certifications
Our Services
Quality guarantee&Service
1. Each machine is manufactured by professional experienced staff.
2. Production process is under strict supervision and adopts China and world toppest production engineering.
3. The warranty time is one year. Quick-wear part is excluded.
4. When warranty date expires, lifetime maintenance service is provided.
5. We can also offer PVC, PE films, BOPP films, stamping dies, hot foil papers etc.
Price governs while the quality is the same.
Service governs while the price equals.
T&D MACHINERY promise to offer perfect after-sale service!
Company Information
FAQ
Q: What is the machine size after packaged?
A: 3250*1180*1230mm
Q: Degree of automation ?
A: Semi-automatic
Q:Heating way , electric heating or oil heating?
A: Oil heating
Q: How to receive the paper,automatic stacker or jogger delivery?
A: Jogger delivery
Q: How to install the machine?
A: Sent the install machine video to you.
Q: How to set the paper size?
A: By the touch screen.
