UHMWPE Cutting Board/PP Board/PE Polyethylene Plastic Board/sheet/panel

UHMWPE Cutting Board/PP Board/PE Polyethylene Plastic Board/sheet/panel photo-1
UHMWPE Cutting Board/PP Board/PE Polyethylene Plastic Board/sheet/panel photo-2
UHMWPE Cutting Board/PP Board/PE Polyethylene Plastic Board/sheet/panel photo-3
UHMWPE Cutting Board/PP Board/PE Polyethylene Plastic Board/sheet/panel photo-4
UHMWPE Cutting Board/PP Board/PE Polyethylene Plastic Board/sheet/panel photo-5
UHMWPE Cutting Board/PP Board/PE Polyethylene Plastic Board/sheet/panel photo-6
US$ 3 - 9 MOQ: 500 Kilograms
Key Specifications
Get Latest Price
Brand Name:
Xinxing
Place of Origin:
Shandong, China
Model Number:
xxpe03-549
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or Tianjin Port China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Xinxing
Place of Origin Shandong, China
Model Number xxpe03-549
Material PE
Size cut to size as your need
Thickness 10-300mm

UHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panel

UHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panelUHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panelUHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panel

UHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panel





Why Choose Us

More than 30 years' professional manufacturing experience with own factory.

Virgin 100% material produced, high quality with good surface and color make ensured

GB/T 19001-2008 ; ISO 9001:2008 certification.

Competitive price, In stock, Fast delivery, and Excellent service.

OEM available. Special character is available :According to different requirements with different application, color, size, shape and special specifications can be customized, such as anti-UV, anti-static and so on.

 The properties of PE cutting board:

Parameter table



No. Item Unit Test standard Result
1 Density g/cm3 GB/T1033-1966 0.95-1
2 Molding shrinkage %   ASTMD6474 1.0-1.5
3 Elongation at break % GB/T1040-1992 238
4 Tensile strength Mpa GB/T1040-1992 45.3
5 Ball indentation hardness test 30g Mpa DINISO 2039-1 38
6 Rockwell hardness R ISO868 57
7 Simply supported beam hardness KJ/m ISO179 85
8 Bending strength Mpa GB/T9341-2000 23
9 Compression strength Mpa GB/T1041-1992 24
10 Static softening temp.   ENISO3146 132
11 Specific heat KJ/(Kg.K)   2.05
12 Impact strength Kj/m3 D-256 100-160
13 Heat conductivity{w/(m.k)} %(m/m) ISO11358 0.16-0.14
14 Sliding properties and friction coefficient PLASTIC/STEEL(WET) 0.19
15 Sliding properties and friction coefficient PLASTIC/STEEL(DRY) 0.14

UHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panelUHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panelUHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panel





Our PE cutting board Characters:

1.very flat on the surface

2.The thickness tolerance is +2 -0,some made according to your requirements.

3.The color is pure and any color can be made by us.

4.We can give you an accurate size of UHMW-PE Sheet with advanced machine.

5.Different shaped UHMW-PE Sheets also can be made by us like bending sheet.

6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant,anti-static and with other characters.

PE Advantages & Key Features:

--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel

--Anti-Weather & Anti-Aging

--Self-lubricating, Very low coefficient of friction

--Excellent chemical & corrosion resistant

--superior impact resistant, Noise- absorption, Vibration-absorption

Temperature range: -2600C ~ +800C; Very high resistance to cold,doesn't become fragile even under -1800C--High tensile Strength

--Non-Toxic and smell

--UV resistance

--Flame Retardant; Relatively low in water absorption

--Excellent electrical properties

--Good performance in resisting environment stress crack, 200 times of ordinary PE

--No adhesion

--Light weight and easier to handle and fix

--Cost efficient; Resulting in low energy consumption

--Does not rot, split or crack; 100% recyclable

--Great liner material for industrial material handling applications

--Easy Reprocessed

Our PE sheet standard sizes:

1.Thickness: 6 - 300mm
2. Width: max 2000mm
3. Normal standard size:

Length(mm)

Width(mm)

Thickness(mm)

2000

1000

6-300

3000

1500

6-300

4700

1200

6-300

5000

1300

6-300

4500

2000

6-300

3050

1220

6-100

Any small size need us to cut , we can satisfy your special need .



Packaging : pallet packing or as client need.





UHMWPE cutting board/PP board/PE polyethylene plastic board/sheet/panel





XINXING can provide various UHMWPE & HDPE products with the good quality at reasonable price according to your requirement.

 Any questions, please feel free to contact us.





Many thanks for you visit us !
