Help CenterScrew Conveyor U-shaped Liner - Screw Conveyor U-shaped Liner
Related Products
-
An-ti Static Uhmwpe Polyethylene Conveyor Belt Impact BarUS$ 5 - 50MOQ: 500 Pieces -
UHMW PE Polymer Truck Lining Board UHMW PE1000 BoardUS$ 55 - 60MOQ: 20 Square Meters
-
UHMW-PE Wear Liner Material for Using With Kaolin Material Surface Protection Sheets, High Performance Polymer LiningsUS$ 5.2 - 5.2MOQ: 300 Kilograms
-
Truck Bed Lining Panel Uhmwpe Lining Panel Uhmwpe Dump Trailer Liner pe Plastic Inner Liner Conveyor Chute Liner Dump Truck BedUS$ 85.5 - 85.5MOQ: 1 Piece
-
Uhmwpe Lining Plate/uhmw-pe Coal Liner Sheet pe Truck Liners Uhmwpe Silo Liner Uhmw Coal Bin Liner Truck Bed LinersUS$ 3 - 9MOQ: 500 Kilograms
Screw conveyor U-shaped liner - Screw conveyor U-shaped liner
Screw conveyor U-shaped liner - Screw conveyor U-shaped liner
Why Choose Us
l More than 15 years' professional manufacturing experience with own factory.
l Virgin 100% material produced, high quality with good surface and color make ensured
l GB/T 19001-2008 ; ISO 9001:2008 certification.
l Competitive price, In stock, Fast delivery, and Excellent service.
l OEM available. Special character is available :According to different requirements with different application, color, size, shape and special specifications can be customized, such as anti-UV, anti-static and so on.
The properties of UHMW-PE:
|
Property |
Unit |
Value |
|
Density |
g/cm3 |
0.93-0.96 |
|
Average molecular weight |
g/mol |
3million- 10 million |
|
Tensile strength (23°C in air) |
MPa |
22 |
|
Breaking strength |
MPa |
42 |
|
Tensile strain at break |
% |
600 |
|
Charpy impact strength (notched) |
mJ/mm2 |
No break |
|
Ball indentation hardness |
N/mm2 |
42 |
|
Shore D hardness |
-- |
65-70 |
|
Abrasion |
% |
70-80, steel = 100 |
|
Static Friction Coefficient |
-- |
≤0.16 |
|
Kinetic Friction Coefficient |
-- |
≤0.10 |
|
Water Absorption |
-- |
NIL |
|
Elongation at break at 23 degress |
% |
≥300 |
|
Temperature resistance |
°C |
-269 to +85 |
|
Melt Temperature |
°C |
130-140 |
Our UHMW-PE sheet Characters:
1.very flat on the surface
2.The thickness tolerance is +2 -0,some made according to your requirements.
3.The color is pure and any color can be made by us.
4.We can give you an accurate size of UHMW-PE Sheet with advanced machine.
5.Different shaped UHMW-PE Sheets also can be made by us like bending sheet.
6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant,anti-static and with other characters.
UHMWPE Advantages & Key Features:
--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel
--Anti-Weather & Anti-Aging
--Self-lubricating, Very low coefficient of friction
--Excellent chemical & corrosion resistant
--superior impact resistant, Noise- absorption, Vibration-absorption
--Temperature range: -2600C ~ +800C; Very high resistance to cold,doesn't become fragile even under -1800C
--High tensile Strength
--Non-Toxic and smell
--UV resistance
--Flame Retardant; Relatively low in water absorption
--Excellent electrical properties
--Good performance in resisting environment stress crack, 200 times of ordinary PE
--No adhesion
--Light weight and easier to handle and fix
--Cost efficient; Resulting in low energy consumption
--Does not rot, split or crack; 100% recyclable
--Great liner material for industrial material handling applications
--Easy Reprocessed
Our UHMW-PE sheet standard sizes:
1.Thickness: 6 - 300mm
2. Width: max 2000mm
3. Normal standard size:
|
Length(mm) |
Width(mm) |
Thickness(mm) |
|
2000 |
1000 |
6-300 |
|
3000 |
1500 |
6-300 |
|
4700 |
1200 |
6-300 |
|
5000 |
1300 |
6-300 |
|
4500 |
2000 |
6-300 |
|
3050 |
1220 |
6-100 |
Any small size need us to cut , we can satisfy your special need .
