Portable HDPE ice rink barrier sheet
Brand: Xinxing
1. Advantege of Complete HDPE ice rink barrier sheet.
Ice Board Sports Systems designs, manufactures, and installs removable arena dasher boards for ice skating, in-line skating, and indoor soccer, football & ball hockey arenas. Our line of dasher boards are suitable for both professional and recreational facilities, indoors or outdoors.
Inexpensive: Low operating and maintenance costs
Usable 365 days a year: The system can be used in any place and in any weather condition.
Easy skating: skating experience similar to that on natural ice
unaffected by the weather or place: year-round skating indoor and outdoor with every weather
Extensive use: use for leisure and professional activities
Long life services: The lifespan is significantly longer than that of the traditional plastic ice-rinks
Complete ice railing: White Dasher Facing, Yellow Kickplate, Blue Caprail, Steel frame, Screws.
2. Details of Complete HDPE ice rink barrier sheet.
We can supply the complete ice rink railing/barriers/dasher board for you, it is including panel, steel frame, steel triangular support, handrail, screw. The installation of ice rink railing/barriers/dasher board is easy and simple. we will design the detailed drawing of ice rink railing/barriers/dasher board according to your demand.
- Designed to withstand years of abuse
- Ideal for facilities where conversions are not an issue
- Fully welded design
- Hot dipped galvanized coated after welding, for corrosion resistance
- The shielding system can be supported or seamless
- Our flush mounted shielding system can be installed on all of our steel dasher board designs
- Complete ice railing: White Dasher Facing, Yellow Kickplate, Blue Caprail, Steel frame, Screws.
please check the following of UHMW-PE/ HDPE ice rick railing/barriers/dasher board:
a. The standard size of our UHMW-PE and HDPE Sheet:
Length x Width x Thickness(mm) |
Length x Width x Thickness(mm) |
2000x1000x(10-100) |
2300x1200x(10-150) |
2500x1300x(10-180) |
3050x1220x(10-60) |
3000x1500x(10-250) |
4500x2000x(10-100) |
4700x1200x(10-150) |
5000x1300x(10-180) |
6000x1800x(20-200) |
6000x2000x(20-100) |
b. Characters of HDPE dasher board, barriers & dasher board systems:
- Very flat on the surface
- The thickness tolerance is +2-0, some made according to your requirement.
- The standard color is white(natural), black, blue, green, red, yellow, orange, and it can be done according to you.
- An accurate size of UHMW-PE sheet with advanced machine.
- Different shaped UHMW-PE Sheets also can be supplied by Abosn like bending sheet.
- According to different requirements with different application, special specification can be customized, like anti-UV, fire-resistant, anti-static and other characters.
- ice rick railing/barriers/dasher board/ leisure rinks barriers/hockey rinks barriers/ Soccer Portable Residential Dasherboards Custom/ Hockey Boards and Rink Perimeter Boards/ Home Hockey Rink Boards
c. Key properties of HDPE dasher board, barriers & dasher board systems :
- Extremely high impact strength
- Excellent wear and abrasion resistance
- Optimal sliding properties
- Dimensional stability
- Energy absorption capacity at high loading rates
- Resistance against fatigue
- Water repellent
- Good chemical resistance
- Excellent electrical and dielectric properties
- Physiologically harmless
- ice rick railing/barriers/dasher board/ leisure rinks barriers/hockey rinks barriers/ Soccer Portable Residential Dasherboards Custom/UV resistance Dasher Board Cap Rail/ Hockey Boards and Rink Perimeter Boards/ Home Hockey Rink Boards.
3. The technical data of Complete HDPE ice rink barrier sheet:
Physical Properties |
Test Method |
Unit |
Value |
Specific Gravity |
ASTM D792 |
g/cm3 |
0.93 |
Water Absorption |
ASTM D570 |
℃ |
<0.01 |
Mechanical Properties |
Test Method |
Unit |
Value |
Tensile Strength |
ASTM D638 |
MPa |
40 |
Elongation, at break |
ASTM D638 |
% |
300 |
Flexural Strength |
ASTM D790 |
MPa |
24 |
Compression Strength, 10% Deformation |
ASTM D695 |
MPa |
21 |
Hardness, Shore D |
ASTM D2240 |
- |
D66 |
Coefficient of Friction |
- |
- |
0.12 |
Thermal Properties |
Test Method |
Unit |
Value |
Heat Deflection Temperature |
ASTM D648 |
℃ |
47 |
Melting Point |
ASTM D3412 |
℃ |
135 |
Continuous Service Temperature |
- |
℃ |
82 |
Electrical Properties |
Test Method |
Unit |
Value |
Surface Resistivity |
ASTM D257 |
Ω-M |
>1015 |
Dielectric Constant 106Hz |
ASTM D150 |
|
2.3 |
General packaging is carton plus stretch film, Pallets, wood packaging. Of course, any packaging can be made according to customer requirements.
Any inquiry and comments please let me know! Thanks in advance!
