For more information ,you can contact by our emai
UHMWPE material outigger pads has the following advantage :
-Apply the Right material for your application
- good tensile strength
-good impact intensity
-super compression strength
-good breaking elongation
-15 Percent the weight of steel pads
-Chemically inert, serviceable from 180° F to - 250° F
-Corrosion, chemical, wear and moisture resistant.
-Non-stick surface, easy to clean.
-Compressive loads up to one million pounds
-Up to 15,000 pounds per square foot
Benefits:
-Work in sub zero temperatures
-Easy to mount, replace
-Reduced downtime.
-Lower maintenance costs.
-Cost Efficient compared to Steel or Aluminum
Application :Our Outrigger Pads put under the support-leg of Truck Crane, Crawler Crane, Rough Crane, Boom Pump, Concrete Pump and so on. It can support Max. load at least 35 MT, for making the machine work safely!
XinXing outrigger pads
are made in UHMWPE, an engineering material that offers a superior combination of impact strength, wear and chemical resistance. Each pad is equipped with a durable wire handle to allow for easy storage and mobility.
PE Outrigger Pads are an alternative to wood pads due to their superior characteristics and performance which allows them to last longer.
Max. Load:350 MT
Feature: Square with rope handle, Convex mark face (skid-proof)
Both virgin and recycled UHMWPE outrigger pads is available
XINXING provides a very strong, durable, and cost-effective footing for all your our Outrigger Pads applications.
XINXING outrigger pad is made of PE material
Because PE material has the following advantage :
--Highest abrasion resistance of any polymer, 6 times more abrasion resistant than steel
--Do not absorb moisture and will not swell up over time due to exposure outdoors.
--Good impact intensity,Do not lose their impact strength over time.
--Good breaking elongation,so they will bend but not break under extreme loads.
--Non-stick surface, easy to clean.
--Corrosion and chemical resistant.
--Noise- absorption, Vibration-absorption
--Super compression strength
--15 Percent the weight of steel pads and easier to handle
--Compressive loads up to one million pounds
--Up to 15,000 pounds per square foot
--Non-Conductive
--Non-Toxic and smell
Benefits:
--Work in sub zero temperatures
--Easy to mount, replace
--Reduced downtime.
--Lower maintenance costs.
--Storage-Friendly
--Durable & Long Lasting
--Cost Efficient compared to Steel or Aluminum
--Safer to use in the field compared to other wood based pads.
Our standard outrigger pads size:
| Dimensions(mm) Square | Weight(kg) | Vertical Jack Capacity (tonne) | Crane Capacity(tonne) |
400*400*40 | 6.3 | 10 | 12 |
| 500*500*40 | 9.9 | 12 | 15 |
| 600*600*40 | 14.2 | 20 | 20 |
| 700*700*40 | 19.4 | 22 | 30 |
| 800*800*40 | 25.3 | 25 | 30 |
| 1000*1000*40 | 39.2 | 30 | 35 |
| 400*400*50 | 8 | 11 | 15 |
| 500*500*50 | 12.2 | 15 | 18 |
| 600*600*50 | 18 | 23 | 30 |
| 800*800*50 | 31.3 | 30 | 35 |
| 1000*1000*50 | 48 | 40 | 50 |
| 400*400*60 | 9.5 | 12 | 15 |
| 500*500*60 | 14.5 | 20 | 25 |
| 600*600*60 | 21.2 | 25 | 30 |
| 800*800*60 | 38.4 | 35 | 45 |
| 1000*1000*60 | 58.5 | 50 | 65 |
| 1200*1200*60 | 85 | 70 | 80 |
| 800*800*70 | 44 | 40 | 50 |
| 1000*1000*70 | 68.5 | 70 | 80 |
| 800*800*80 | 50.4 | 50 | 60 |
| 1000*1000*80 | 78 | 80 | 100 |
| 1200*1200*80 | 113 | 100 | 120 |
| 1000*1000*80 | 98 | 110 | 140 |
| 1200*1200*100 | 141 | 140 | 160 |
Xinxing UHMWPE sheet standard sizes:
1.Thickness: 6 - 300mm
2. Width: max 2000mm
3. Normal standard size:
Length(mm) | Width(mm) | Thickness(mm) |
2000 | 1000 | 6-300 |
3000 | 1500 | 6-300 |
4700 | 1200 | 6-300 |
5000 | 1300 | 6-300 |
4500 | 2000 | 6-300 |
3050 | 1220 | 6-100 |
Any small size need us to cut , we can satisfy your special need .
Packaging : pallet packing or as client need.
