Home > Electrical & Electronics > Electric Motor > DC Motor > 390 DC12V 22000RPM Large Torque High Speed Carbon Brush Motor for Electric Drill
390 DC12V 22000RPM Large Torque High Speed Carbon Brush Motor for Electric Drill
US$ 0.6 - 0.9
MOQ: 5000 Pieces
Key Specifications
Get Latest Price
Brand Name:
MBI
Place of Origin:
Hunan, China
Model Number:
RS-390395SHPH
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
25x20x15mm 130 DC Motor 3V 16500RPM 350mA For Driving Toy DIY HobbyUS$ 0.2 - 0.5MOQ: 5000 Pieces -
DC12-24V 3000-20000rpm RS775 Double Shaft High Speed DC MotorUS$ 2.5 - 3.5MOQ: 5000 Pieces
-
DC 3-12V < 300RPM Mini Metal Gear Motor Model N20US$ 0.5 - 0.7MOQ: 5000 Pieces
-
2 x DC6V 15000RPM High Torque N20 Bare Magnetic Carbon Brush Electric Motor for ToysUS$ 0.4 - 0.8MOQ: 5000 Pieces
-
Jtron Mini Magnetic N20 Bare Carbon Brush DC MotorUS$ 0.4 - 0.8MOQ: 5000 Pieces
Brand Name
MBI
Place of Origin
Hunan, China
Model Number
RS-390395SHPH
Type
Micro Motor
Certification
CCC, CE, ROHS, UL, VDE
Torque
97.9g.cm
Usage
Home Appliance
Construction
Permanent Magnet
Efficiency
Other
Protect Feature
Totally Enclosed
Continuous Current(A)
0.81A
Speed(RPM)
5972rpm
Commutation
Brush
| 390 DC12V 22000RPM 390 Large Torque High Speed Carbon Brush Motor for Electric Drill |
Product Description
Outline drawing:
Technical datas:
Motor Diameter: about 29mm
Motor Body Length: about 50mm
Output Shaft Diameter: about 2.3mm
Output Shaft Length: about 15mm
Motor Step Diameter: about 10mm
Motor Step Height: about 3mm
Mounting Hole Diameter: M2.5
Mounting Hole Distance: 16mm
Weight: about 100g
Voltage Range: DC3V-12V
Test:
Voltage: DC3V No-load Speed: 4500rpm No-load Current: 0.26A Stall Current: 0.95A
Voltage: DC6V No-load Speed: 11000rpm No-load Current: 0.4A Stall Current: 0.9A
Voltage: DC12V No-load Speed: 22000rpm No-load Current: 0.42A Stall Current: 2.86A
Application:
Motorized toys, N-scale train models, Toys and Models, Plastic toys, fan toys, education toys etc
