3.7v Cl-0716 Coreless dc Motor 7mm

3.7v Cl-0716 Coreless dc Motor 7mm thumbnail-1
3.7v Cl-0716 Coreless dc Motor 7mm thumbnail-2
3.7v Cl-0716 Coreless dc Motor 7mm photo-1
3.7v Cl-0716 Coreless dc Motor 7mm photo-2
US$ 0.67 - 0.67 MOQ: 10000 Units
Key Specifications
Get Latest Price
Brand Name:
chaoli
Place of Origin:
Guangdong, China
Model Number:
CL-0716
Contact Supplier Request Quote Chat Now
Guangdong Chaoli Motor Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShanTou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name chaoli
Place of Origin Guangdong, China
Model Number CL-0716
Product Description



CL-0716 Coreless Motor





Application: Massager, Vibration, Toys Vibrator, Sex Toys, Massage Rod, Massager Device, Sex Toys, Massage Rod, Massager Device, PCS (Personal Communication by Satellite), Eye Massagers, Medical Products and other electric appliance.






BASIC INFORMATION
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
Terminal resistance

Model
Calculate KV
Operation range
Nominal
Current
Speed
Current
Speed
Efficiency
Torque
Power
Current
Torque
rpm /V VDC VDC mA r/min mA r/min ηmax mN.m gf.cm mW A mN.m gf.cm
CL-0716 9.1 1.5~4.0 3.0 55.0 27200 314.6 23153 68.10% 0.265 2.704 642.7 1.80 1.782 18.17 1.67
11.6 1.5~4.5 3.7 80.0 43000 530.7 37367 72.12% 0.362 3.691 1416.0 3.52 2.762 28.18 1.05
11.9 1.5~4.0 3.2 73.0 38100 440.7 32685 69.61% 0.287 2.925 981.5 2.66 2.018 20.58 1.20
12.8 1.5~4.0 3.2 110.0 41000 590.3 34560 66.20% 0.346 3.525 1250.5 3.17 2.200 22.44 1.01
14.0 1.0~3.0 1.5 100.0 21000 316.2 15955 46.75% 0.133 1.354 221.8 1.00 0.552 5.64 1.50
14.1 1.5~4.5 3.7 110.0 52000 731.2 45200 72.17% 0.413 4.208 1952.4 4.86 3.154 32.18 0.76
15.1 1.5~4.5 3.7 170.0 56000 893.9 47052 65.58% 0.440 4.490 2168.8 4.70 2.755 28.10 0.79
16.2 1.5~4.5 3.7 150.0 60000 979.8 52034 71.73% 0.477 4.867 2600.0 6.40 3.594 36.66 0.58
16.4 1.5~4.0 3.2 125.0 52400 796.9 45295 71.09% 0.382 3.898 1812.6 5.08 2.818 28.75 0.63
17.2 1.5~4.0 3.2 180.0 55000 868.4 45557 62.84% 0.366 3.734 1746.3 4.19 2.132 21.75 0.76
18.0 1.5~4.0 3.0 220.0 54000 1185.0 45545 66.32% 0.494 5.042 2357.4 6.38 3.157 32.20 0.47
 3.7v cl-0716 coreless dc motor 7mm3.7v cl-0716 coreless dc motor 7mm
