Help CenterMicro Coreless Motor Chaoli CL 820 8.5x20mm for 90mm-150mm DIY Micro FPV RC Quadcopter Frame-chaoli2016
Related Products
-
Chaoli Small Coreless Motor CL-0615 and CL-0617 With 15KV 17KV and 19KV for Tiny Whoop and DIY Micro FPV Quadcopter-chaoli2017US$ 0.95 - 1.35MOQ: 2000 Units -
China Cheap 8mm and 3.2V Coreless Small Motor With 16mm Length CL-0816 for Racing Drone and Mini Quadcopter-chaoli2016US$ 1.05 - 1.45MOQ: 2000 Units
-
Coreless Motor CL-0820-18kv 58000rpm Motors 3.2v 1s and 7.5kv 52000rpm Motors 7.0v 2s -chaoli2016US$ 1.25 - 1.65MOQ: 2000 Units
-
7mm New DIY Micro FPV RC Quadcopter Coreless Motor CL-0720 With 30000~45000rpm-chaoli2016US$ 1.15 - 1.55MOQ: 2000 Units
-
Chaoli CL-615 6x15mm Coreless Motor for 90mm-130mm DIY Micro FPV Quadcopter Frame Blade Inductrix-chaoli2016US$ 0.95 - 1.35MOQ: 2000 Units
1.This product
- Below are the specifications and structures of the product, for more information, please feel free to contact us.
- Furthermore, we provide customizable service of micro dc motor/generator, including consulting, design and manufacture services, all the products are made to your order.
Special features/structure:
Motor type: PMDC coreless motor
Motor housing (D*F* L): Φ8.5*20.05mm
Housing material: SECD-O
Shaft (diameter): 1.0mm SUS304 steel (nickel coating)
Way of commutation: precious metal-brush
Structure: 2-pole stator and hollow cup type
Magnet type: Nd-Fe-B
Rotation: CW/CCW and reversible
Weight: 5.0g (approximate)
Options:
Length and shape for the extended shaft
EMI/EMC suppression
Gear, eccentric wheel or reducer increased
Magnet type
MICRO-JST-1.25 plug
Wire diameter and turn number
Key parameters/performance
Rated voltage: 3.2V DC
At no load:
Speed: 57500rpm
Current: 270mA
At stall:
Current:5.39A (maximum)
Torque: 55.0gf.cm
This product is widely used in:
Medical equipment, electric shaver, electric toothbrush, electric make-up puff, facial cleaning apparatus, eye care massager, small household appliance, precise instruments, massager, game controller, aeromodelling, mini drone, quadrocopter, UAV;servo, sex product.
Provide high quality, Bring honorable value.
2.Our products
Following are the main products of our company, including coreless dc motors, brush dc motors, brushless dc motors, flat vibration motors and micro generators, etc., covering a wide range of around 1,000 products.
Our advantages:
.Specialized manufacture
. Complete variety of product
.Volume production ability
.Reasonable pricing with high quality
.Short leading time, customized service
Please send us inquiries table including specifications
for the performance and structure requirements .
