XJC-25(D) Series Pendulum impact tester

XJC-25(D) Series Pendulum impact tester

Application:

Charpy Impact test is used for test engineering plastics, glass-steel, ceramics, casting stone, plastic wiring, insulating material, plastic pipe material and other non –metallic materials for anti- impact intensity.

The products satisfy the standard demands of ISO 179, ISO 180,GB/T 1043, GB/T 1843,ASTM D256,DIN53453,GB18743,ISO9854,DIN12608 and others. Each type has both electronic type and pointer type.

The electronic type adopts raster -display technique of measuring circle angle, with the characteristics of high precision, good stability and wide range of measuring, digital display of testing split strength, impact intensity,fore-elevation, ascending angle, automatic orrecting average value of one group for energy losing.

Main technical parameter:

1.Distance between clamps of Charpy:  40mm  60mm  70mm  95mm

2.(Izod) Impact energy:  1J  2.75J  5.5J  11J  22J   impact speed: 3.5m/s

3.(Charpy)Impact energy:  1J  2J  4J  5J  7.5J  15J  25J

4.impact speed: 2.9m/s and 3.8m/s

Three Star Service :

*First Star---Pre-service

    24 Hours online service for your consult.

    Help choose right model,and a series  of service,person,advise.

*Second Star---Middle Service

    --Give you best offer

    --Provide discount for many sets order

    --Do customer's request

    --Choose payment term you convienent.

    --Promptly production and delivery,inform you in time.

    --Can provide invoice value as you like to decrease your tax.

. *Third Star---After serivce

   --1 year warranty service and all life maintenance.

   --Technical Egineer are avalible for oversea trainning.

   --Free change for some parts

   --Provide newest software vision when update

   --Remote control technical consult

   --Free installation DVD

   --Maintenance plan

About us:

--OEM,ODM avaliable.

--CE ISO Certification

--Three Star Service

--Near Qingdao sea port,high quality,good service

-- 200 workers,1000m2 non-dust workshop,20 years experience

--We have our own brand PTE and it has high reputation at home and abroad.We have so many agents in the world

Trust Us,Trust PTE!  Let us do the best service for you !
