Gantry Type Universal Wire Tension Testing machine + Lab Wire/Rope Electric Tension Measuring Equipment

Door Type Universal Wire Tension Tester

WDS-10 Microcomputer-controlled electronic universal testing machine is mainly used for testing mechanical properties of various metals, non-metals and composite materials such as tensile, compression, bending, shear, stripping, tearing, etc. The system adopts microcomputer closed-loop control, which can realize constant velocity displacement, constant velocity stress, constant velocity strain and can be programmed. The design of the test machine has the characteristics of beautiful appearance, convenient operation, stable and reliable performance, no pollution, low noise, and high efficiency. The design of the auxiliary equipment is matched with the main machine. The structure is wedge-type translational and manual rotary clamping. The specimen is not subject to additional force. Convenient, reliable and non - slip clamping.

The working environment should be free from vibration and dust. At room temperature (15-25); Humidity < 70%; Surrounding no vibration, no corrosive medium, no strong magnetic field interference; Power supply voltage fluctuation not exceeding 10% of rated voltage.

This machine is widely used in such  mechanical property tests of tensile, compression, bending, peeling, tearing, shearing, puncture, adhesive strength in metal and non-metallic materials, such as in steel, spring, plastic, rubber, fabric, ropes, belts, man-made board, paper, building materials, composite materials, waterproof materials, packaging materials, medical supplies etc.

Grips Specification:

The equipment is equipped with a set of tensile attachment, bending attachment and compression attachment respectively.

1.The grips size for 100kn: round:4-9, 9-14, 14-20; flat: 0-7, 7-14,14-20) .Please confirm before shipment.

2. Compression plate size: 100mm * 100mm, which can be customized according to special requirements, as the max size can be up to 400mm * 400mm.

3. Size of three-point bending attachment: the diameter of the roller is 20mm, which can be customized according to special requirements.

Jinan Chuanbai Instrument Equipment Co., Ltd, located in Jinan city, Shandong province-the national test machine production base, is a collection of scientific research and development as one of the high-tech production enterprises. We have been producing professional UTM and various test equipment for 12 years. We have had great success in both China and the international market. Since the establishment, we have been committed to the research and development of mechanical testing instruments with a leading position with such hydraulic universal testing machine, electric universal testing machine, compression testing machine, impact testing machine, fatigue testing machine, torsion series machine, horizontal tensile testing machine, and other customized products. And we will always welcome to any inquiry about the equipment on our website:, where you can better understand us here.

Q: What is the accuracy of the equipment?

A: Two kind of measurement accuracy with grade 1 and grade 0.5 respectively.

Q: What is the test space?

A: Normally, it is 800mm, can be customized of1500mm

Q: What is the brand for the sensor?

A: Normally, most of the brands for the sensor is Guandong Guangce(brand). Also, the configuration of CELTRON and Transcell can opt as special demands.

Q: What is the brand for the motor?

A: Normally, most of the brands for the motor is Speecon. Also, the Panasonic brand can opt as special demands.

Q: When will the order be delivered?

A: Usually about 10-28 days. If we have inventory, we can arrange the delivery within 3 days after the retest in the laboratory. Please note that our products delivery time depends on the specific equipment and quantities.

Q: What about the warranty?

A:  12 months. In addition, we can help you feel free to fix your problem controller, even if it doesn't come from our factory. After the warranty, the professional after-sales service team will provide perfect technical support to help customers solve the problems encountered when using our products, and deal with customers' problems and complaints in a professional and timely manner.

Q: How about the service and quality of the products?

A: Each equipment must be 100% inspected and tested during transportation and delivery. Product use training, we can send you the video for training to show you how to install and operate. We can arrange engineers to train the operation of the equipment for you when necessary. We made an amazing reputation in this field.
