Automatic Horizontal Lipstick Blood Test Tubes Labeling Machines
Suitable for the unstable circular cylindrical objects, semi circle labeling, horizontal transmission,horizontal labeling way, increasing stability, improving the labeling efficiency.
Optional printer or inkjet coder attached to the labeling applicator, it can print on the label production date,batch number and barcode printing information.
Core working principle: The sensor detects the product passing through after the product is separated by the bottle dividing mechanism,and then returns the signal to the labeling control system, which controls the motor in the appropriate position to send the label to be attached to the labeling position.The product flows through the labeling device; the labeling tape rotates the product; and the label is rolled over; thus a label’s sticking is completed
| Model | HL-T-402 | |
| Labeling Accuracy | ±0.5mm | |
| Labeling Speed | Stepping:100~200pcs/min Servo:150~300pcs/min | |
| Applicable Dimensions | φ10mm~φ22mm | |
| Applicable Labe Size | Length:20-100mm Width:20-110mm | |
| Power Supply | 220V/50HZ | |
| Weight | 200KG | |
| Machine Size(LxWxH) | About 2050mm x 650mm x 1450mm | |
| Delivery Time | 30-35ays | |
| Type | Manufacture, Factory,Suppier | |
| Packaging | Wooden box | |
| Shipping Method | Sea.Air and Express | |
| Payment Term | L/C,T/T,Money Graml etc | |
High speed: the device uses horizontal roller conveyor with conveying tilted chain to enable automatic correction of bottle status,and stably load bottles to be labeled. Labeling speed: 400 bottles/minute, significantly saved manpower and materials;
Low occurrence of bottle breakage: use flexible bottle separation technology and flexible label covering technology to smooth bottle labeling with the bottle breaking rate brought under 1/100000;
High quality labeling: using deviation rectification technology to correct rounded label, high superposition of both ends of labels attached; the rolling label covering offers smooth labeling free of any wrinkles or bubbles, thus bettering packaging quality;
High stability An advanced electronic control system that is composed of Panasonic PLC+ Panasonic touch screen + Panasonic pinhole electric eye + Germany Leuze label detecting electric eye enables 24×7 equipment operation;
Intelligent control Automatic photoelectric tracking that avoids idle labeling while correcting and detecting labels automatically,so as to prevent mislabeling and label waste;
Sturdy and durable It is made of stainless steel and premium aluminum, meeting the GMP production requirements. It looks great.
Technical parameters: The technical parameters of the standard model are shown as follows.Customization is available if there are any particular requirements of functions.
Click here for more than discount
Our service
Pre-sales Services:
1.Over 5,000 professional labeling video,give you direct feeling about our machine.
2.Free labeling solution from our chief engineer.
Medium-sales Services:
Huanlian have the trained team to follow your orders methodically to guarantee the products can be finished on time with high quality.
After-sale Services:
1. Manules / Videos of machine installation, adjusting, setting, maintenance are available for you.
2. If any problems happend and you can not find out the solutions, Telecom or Online face to face communication available 24 hours.
3. Huanlian engineers & technician are available send to your countries for services if you agree pay the expenditure.
4. The machine will have One year guranty for machine, two years guaranty for electrical part. During the warranty year if any of the parts broken not by man-made. We will free charge to replace the new one to you. The warranty will begin after the machine send out we received the B/L.
5. Huanlian has an independent team for after-sale service. Any emergency please call the saleman or our after-sale's manager.
1) Q:Are you a factory or trading company
A:Yes,We are the manufacturer,Our company is engaged in the labeling machine industry for more than ten years
2) Q:Where are your products distributed?
A:Our products are distributed all over the world,Manin market are Europe,Noth America,The united Arab emirates,Africa and so on.
3) Q:Which port is the nearest from you?
A:Shenzhen port
4) Q:What’s your lead time?
A:Normally 15-25days after we receive your deposit.
5) Q:We are afraid you won’t deliver us the machine after we pay you the money?
A:Please note our above business license and certificates,and if you don’t trust us,you can use Alibaba’s trade assurance service or by L/C.
