HAS VIDEO SJ-A Mini Polyethylene HDPE LDPE Plastic Film Blowing Machine Price For Package Bag,Agriculture Cover
- Ningbo China
- T/T Credit Card
You May Like
Product Details
| Brand Name | XIAOHAI | Place of Origin | Zhejiang, China | |
| Model Number | SJ-M | After-sales Service Provided | Engineers available to service machinery overseas | |
| Condition | New |
seaworthy package for mini hdpe film blowing machine
Product Description
LDPE hdpe film blowing machine
Usage:
1.It is used for blowing the plastic film of low density polyethylene(LDPE), high density polythylene(HDPE)and linear low density polyethylene(LLDPE) etc.
2.The film is widely used for packing bag,such as T-shirt bag,shopping bag,clothing bag,garbage bag and agriculture covering film etc
Specification:
Model No. | SJ-B50 | SJ-B55 | SJ-B60 |
Screw Diameter | 50mm | 55mm | 60mm |
Screw Ratio(L/D) | 28:1 | 28:1 | 28:1 |
Max.Folding Width of Film | 600mm | 800mm | 1000mm |
Single side thickness of Film | 0.008-0.08mm | 0.008-0.08mm | 0.008-0.08mm |
Power of Main Motor | 11KW | 15KW | 18.5KW |
Output | 40kg/h | 50kg/h | 60kg/h |
Total Power | 22Kw | 26Kw | 30Kw |
Weight of Machine | 2000kg | 2300kg | 3000kg |
Dimension(mm) | 5700x1800x3600 | 6000x2000x4000 | 6500x2200x4500 |
Model No. | SJ-B65 | SJ-B80 | SJ-B100 |
Screw Diameter | 65mm | 80mm | 100mm |
Screw Ratio(L/D) | 28:1 | 28:1 | 28:1 |
Max.Folding Width of Film | 1200mm | 1500mm | 2000mm |
Single Side Thickness of Film | 0.008-0.08mm | 0.008-0.08mm | 0.008-0.08mm |
Power of Main Motor | 22KW | 30KW | 45KW |
Output | 70kg/h | 100kg/h | 160kg/h |
Total Power | 42Kw | 56Kw | 88Kw |
Weight of Machine | 3800kg | 4600kg | 60000kg |
Dimension(mm) | 6800x2400x4800 | 7000x2700x5500 | 8000x3200x7600 |
Model No. | SJ-B100 | SJ-B110 | SJ-B120 |
Screw Diameter | 100mm | 110mm | 120mm |
Screw Ratio(L/D) | 28:1 | 28:1 | 28:1 |
Max.Folding Width of Film | 2000mm | 2500mm | 3000mm |
Single Side Thickness of Film | 0.02-0.08mm | 0.02-0.08mm | 0.02-0.08mm |
Power of Main Motor | 55KW | 75KW | 90KW |
Output | 160kg/h | 190kg/h | 220kg/h |
Total Power | 88Kw | 106Kw | 126Kw |
Weight of Machine | 60000kg | 9000kg | 12000kg |
Dimension(mm) | 8000x3200x7600 | 9000x3700x8700 | 1000x4200x9800 |
|
|
|
The machinge body is channel steel frame traction frequency friction,with single rolling friction,lift up and down which is suitable for blowing high-low pressure polyethylene industral fiml and agricultural film.
Specification:
Model | SJ-A45 | SJ-A50 |
Suitable Material | LDPE,HDPE,LLDPE | LDPE,HDPE,LLDPE |
Screw Diameter | 45mm | 50mm |
Film Width(mm) | 100-480 | 300-580 |
Film Thickness (mm)(HD) | 0.009-0.05 | 0.009-0.05 |
Film Thickness (mm)(LD) | 0.02-0.15 | 0.02-0.15 |
Max Extrusion Output(kg/h)(HD) | 40 | 45 |
Max Extrusion Output(kg/h)(LD) | 4550 | 50 |
Screw L/D Length | 28:130:1 | 28:130:1 |
Main Motor(kw) | 7.5 | 11 |
Take-up Motor(kw) | 0.75 | 1.1 |
Outline Dimension(L×W×H)(m) | 5.0×2.0×4.1 | 5.0×2.2×4.5 |
If you need combine to 1 color Flexo printing machine, need add another USD 2500
Company Profile
We are a Big Group specializing in making all kinds of printing and plastic machines, such as plastic bag whole line machines (film blowing machines, flexo and gravure printing machines, lamination machines, all kinds of bag making machines), disposable glove making machines, plastic cup and paper cup making whole line machines, drink straw making whole line machines, label whole line making machines, and paper cutting whole line machines.
