Help CenterFull Automatic Half Full Body Cap Cup Bowl Container PVC PET Shrink Label Sleeving Machine
Related Products
-
520*320mm Big Size BOPS/PVC/PET ,Hardware , Food , Pharmaceutical Tray Forming and Cutting Machine In One StepUS$ 9,900 - 10,700MOQ: 1 Set -
450mm Big Size Plastic Cup Lid Small Container Thermoforming Machine For PS/PVC/PET ,Hardware , Food , Pharmaceutical TrayUS$ 9,900 - 10,700MOQ: 1 Set
-
2016 HAS VIDEO Paper Cup and Plastic Cup Making Machine For Coffee , Juice DrinkingUS$ 5,000 - 20,000MOQ: 1 Set
-
2016 HAS VIDEO CK660 Disposable Plastic Cup Making Machine Price for Thermoforming Juice Water CupUS$ 1 - 2MOQ: 1 Set
-
2016 HAS VIDEO PP PS PE Plastic Sheet Extruder For File Cover. Plastic Cup And Cup Lid And All Kinds of Plastic CoverUS$ 32,000 - 35,000MOQ: 1 Set
Auto Sleeve Machine is for applying heat shrinkable sleeve label or neckbands which is commonly used on most food packages ranging from bottles, yogurt cups, margarine bowls and eye drop containers. Shrink sleeves can wrap and conform to a container's every curve, enabling complete decoration of unusual shapes from top to bottom with 360 degrees. Shrink sleeves are widely used to decorate everything from foods, beverages, cosmetic, medical and even personal products like eye drop, etc.
AUTO SHRINK LABEL SLEEVE MACHINE
New Generation MODEL XHL-250
(1)Main machine size:2000L x 860W x 1800H mm
(2)Main Body: SUS304 Stainless Steel
(3)Weight:about 500kgs (main machine)
(4)Bottle diameter Range (Blade Plate):Φ20~Φ50mm,Φ50~Φ90mm,Φ90~Φ130mm,one dimension can be choose from three options, special specification can be made to meet customers’ demands.
(5) Label Material: OPS, PVC, PE, PET,ETC
(6)Label height:20mm ~ 300mm
(7)Thickness of label:0.03mm ~ 0.13mm
(8)Sleeve reel Inner core:5" ~10"
(9)Maximum Speed:250bpm (Sleeve cut length within 100mm)( The longer the length of the label, the slower the speed, the accuracy speed should be after testing the client’s bottle sample.)
(10)Voltage:3 phase / 220V or 380V(can be changed to customer's voltage format)
(11)Consumption power:main machine 2.5KW
STEAM SHRINK TUNNEL (MODEL S-2000)
(1)Main machine size
LxWxH 2000mmX 550mmX1000mm
(2)Machine body&Weight SUS304 160KGS
(3)Stainless Steel SUS 304
(4)Power AC 3-PHASE220/380V
(5)Fan motor 0.5KW
(6)Steam pressure 0.5~3MPa
(7)Steam consumption 30~80kg/Hr
(8)Others:Equipped with Water Drain Pan and Support
(9)Stainless Steel body 2mm thickness
