Machine Name: SJ-25 mini laboratory film blowing machine
Usage:
1.It is used for blowing the plastic film of low density polyethylene(LDPE), high density polythylene(HDPE)and linear low density polyethylene(LLDPE) etc.
2.The film is widely used for packing bag,such as T-shirt bag, shopping bag, clothing bag, garbage bag and agriculture covering film etc.
Specification:
Model |
SJ-25 |
Suitable material: |
PE,EVA,PLA |
Screw Diameter |
25mm |
Screw Ratio |
L/D28:1 |
Screw speed |
50-90r/min |
Main Output |
4-5kg/h |
Power of Main Motor |
3.0kw |
Specification of Die Head |
Φ40mm |
Single-side Thickness of Film |
0.008-0.03mm |
Max. Folding Width of Film |
200mm |
Total Power |
8kw |
Weight of Machine |
400kg |
Overall Dimension(L*W*H) |
1800*1000*1700 |
we also have more high output machine,please tell me your request,so we can do the best service for you.
see the process:
