Brief introduction:
Economic type laminated film bag making machine, it is used for various kinds of laminated material, meanwhile, it also has three sides sealing bag, side gusset of center sealing bag, stand up bag and zipper bag etc...
Specification of Electrical
The main electric configuration traction three servo motor, with Taiwan industrial control computer, and the main drive for ac motor with frequency converter on, temperature control and road, put volumes constant tension
Application of material
BOPP. COPP. PET. Of PVC, agriculture, plastic composite film multi-layer co-extruding film, aluminum composite film, zhisu composite film, pure aluminum foil composite film
Technical parameter:
TYPE |
WFD 500 |
The max speed of running |
180times/min |
The speed of min unwinding |
≤35m/min(according the material) |
Size of bag |
Length: within 400mm or 800mm(according to customers’ demands) Max Width: 500mm |
Diameters of fabric |
600x1250 mm |
Degree precision |
≤±0.5mm |
Hot sealing knife quantity |
1.Vertical sealing use up and down 5 groups 2. Horizontal sealing use up and down 3 groups,cold sealing 2 groups |
Electric Block |
16pcs |
The range of temperature |
0~300°C |
Total Power |
46KW (usually it is 35KW if good condition, if heat preservation it is 15kw) |
Over size |
8000×1900×1870mm(L×W×H) |
Weight of machine |
about 4500KGS |
Color of cover |
green cover and black machine |
The model of control system |
Industrial controlling computer composite film high-speed bag making machine control system |
