Machine Name: plastic film extruder machine
Usage:
1.It is used for blowing the plastic film of low density polyethylene(LDPE), high density polythylene(HDPE)and linear low density polyethylene(LLDPE) etc.
2.The film is widely used for packing bag,such as T-shirt bag, shopping bag, clothing bag, garbage bag and agriculture covering film etc.
SJ-B Series is the machines with rewinder and rotary head. If you do not need these two device, we have the machines SJ-A Series.
Specification:
Model No. | SJ-B50 | SJ-B55 | SJ-B60 |
Screw Diameter | 50mm | 55mm | 60mm |
Screw Ratio(L/D) | 28:1 | 28:1 | 28:1 |
Max.Folding Width of Film | 600mm | 800mm | 1000mm |
Single side thickness of Film | 0.008-0.08mm | 0.008-0.08mm | 0.008-0.08mm |
Power of Main Motor | 11KW | 15KW | 18.5KW |
Output | 40kg/h | 50kg/h | 60kg/h |
Total Power | 22Kw | 26Kw | 30Kw |
Weight of Machine | 2000kg | 2300kg | 3000kg |
Dimension(mm) | 5700x1800x3600 | 6000x2000x4000 | 6500x2200x4500 |
Model No. | SJ-B65 | SJ-B80 | SJ-B100 |
Screw Diameter | 65mm | 80mm | 100mm |
Screw Ratio(L/D) | 28:1 | 28:1 | 28:1 |
Max.Folding Width of Film | 1200mm | 1500mm | 2000mm |
Single Side Thickness of Film | 0.008-0.08mm | 0.008-0.08mm | 0.008-0.08mm |
Power of Main Motor | 22KW | 30KW | 45KW |
Output | 70kg/h | 100kg/h | 160kg/h |
Total Power | 42Kw | 56Kw | 88Kw |
Weight of Machine | 3800kg | 4600kg | 60000kg |
Dimension(mm) | 6800x2400x4800 | 7000x2700x5500 | 8000x3200x7600 |
Model No. | SJ-B100 | SJ-B110 | SJ-B120 |
Screw Diameter | 100mm | 110mm | 120mm |
Screw Ratio(L/D) | 28:1 | 28:1 | 28:1 |
Max.Folding Width of Film | 2000mm | 2500mm | 3000mm |
Single Side Thickness of Film | 0.02-0.08mm | 0.02-0.08mm | 0.02-0.08mm |
Power of Main Motor | 55KW | 75KW | 90KW |
Output | 160kg/h | 190kg/h | 220kg/h |
Total Power | 88Kw | 106Kw | 126Kw |
Weight of Machine | 60000kg | 9000kg | 12000kg |
Dimension(mm) | 8000x3200x7600 | 9000x3700x8700 | 1000x4200x9800 |
Model No. | SJ-A50 | SJ-A55 | SJ-A60 |
Screw Diameter | 50mm | 55mm | 60mm |
Screw Ratio(L/D) | 28:1 | 28:1 | 28:1 |
Max.Folding Width of Film | 600mm | 800mm | 1000mm |
Single Side Thickness of Film | 0.008-0.08mm | 0.008-0.08mm | 0.008-0.08mm |
Power of Main Motor | 11KW | 15KW | 18.5KW |
Output | 30kg/h | 40kg/h | 50kg/h |
Total Power | 18Kw | 22Kw | 26Kw |
Weight of Machine | 1500kg | 1800kg | 2100kg |
Dimension(mm) | 4800x1800x3600 | 5000x2000x4000 | 5200x2200x4400 |
see the process:
the double rewinder set:
This is the gusset to make the edge fold:
the whole machine:
the rotary head:
Remark:
We also have wider width machine,if you have interest,please feel free to contact us,we will provide you details.thanks.
