Our company is specialized is engaged in the liquid filling machine development

Name: Our company is specialized is engaged in the liquid filling machine development
Brand: JOYGOAL
Price: USD $3,000 - 10,000 / Set

FOB Price

USD $3,000 - $10,000 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port shanghai
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	JOYGOAL	Place of Origin:	Shanghai, China	Certification:	CE
After-sales Service Provided:	Engineers available to service machinery overseas	Weight:	480kg	Dimension(LWH):	12008502050mm
Voltage:	220V/380V	Power:	2.1KW	Application:	Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Condition:	New	Automatic Grade:	Automatic	Driven Type:	Pneumatic
Packaging Material:	Glass, Metal, Paper, Plastic, Wood	Packaging Type:	Bags, Barrel, Bottles, Cans, Capsule, Cartons, Case, Pouch, Stand-up Pouch, Bags

Packaging Details

wooden case

Product Description

Intr Introduction:

Description:

water filling packing machine
This machine is high precsion and most advanced liquid packing machine in China, which is three sides sealing, intermittent and vertical.

Features:

1. Automatically finish the processes of pouch forming, filling, sealing, cutting, date printing for pillow pouch packaging.

2. Two types suit for single layer PE film and laminated films.

3. PLC controller and A Pattern calibration photoelectric controller device, ensure the patterns will be complete and beautiful.

4. Quantitative piston pump filling ensure packaging volume can be adjusted within accurate range.

Technical Parameters:

Model	YT-500B	YT-1000B	YT-2000B
Packing speed	1100-1300pouch/h	1100-1300pouch/h	800-1000pouch/h
Filling volume	50-500ml	200-1000ml	500-2000ml
Power	220V/380V 2.1kw	220V/380V 2.5kw	220V/380V 2.5kw
Film width	150-320mm	150-380mm	150-450mm
Weight	300KG	400KG	480KG
Size	8807601800mm	10508502050mm	12008502050mm

The product of machine:

Company profile

Shanghai Joygoal Food Machinery Co.,Ltd a professional factory producing food machinery and packing machinery. We provide low price&high quality machines. In case of our machines, it'll reduce your cost dramatically and increase your production. So do contact us for further infromation. Sincerely hope our clients ride on the crest of success.

Welcome to visit us!

Q3:How to place my order?

A: Just contact us via TraderManager, E-mail, Skype or telephone to confirm the product, make the deposit then we will start to manufacture.

Q4:What is the payment term?

A: 30% T/T deposit and 70% T/T balance payment before shipping.

Q5:How long is the delivery time?

A: About 35- 40 working days.
