electric automation device dcl-k05 dcl-k10 dcl-k20

FOB Price

USD $300 - $700 / Piece

1 Piece(Min.Order)

Supply Ability 100 Piece / Pieces per Month
Port TIANJIN XINGNAG PORT
Payment TermsT/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
Delivery Detail15 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Freya		Place of Origin	China
Model Number	dcl-k05 dcl-k10 dcl-k20

Product Description

DCL series electric actuator are used to control 0-90° rotation valve and other similar products such as butterfly valve, ball valve, throttle plug valve, louver valve, etc . It uses AC24V, 110V, 220V , 380V , and DC 24V voltage to be the driving source, 4-20mA current signal or 0-10V voltage signal to the controlling signal driving the valve to the required position, so that realized the automation control. They can be widely used in petroleum, chemical,electric power, metallurgy, papermaking, water treatment, shipbuilding , food processing and building automation. At the same time, it has the advantages of small size, light weight , beautiful appearance , unique structure , compact structure, quick opening and closing, easy installation , small

operating torque, convenient operation, no need for maintenance and safe and convenient use of digital display valve position.

Model Performance	DCL-K05	DCL-K10	DCL-K16	DCL-K25	DCL-K50e	DCL-K100	DCL-K200

Model	DCL-K02	DCL-K05	DCL-10	DCL-K20	DCL-K40	DCL-K60	DCL-K100	DCL-K160	DCL-K250
Torque (NM)	18	50	100	200	400	600	1000	1600	2500
