Los Angeles Abrasion Testing Machine with Abrasive charges
- 100 Set / Sets per Month
- xingang
- T/T Credit Card
You May Like
-
asphaltic bitumen testing equipment asphalt centrifugal extractors, centrifuge extractors
-
asphalt binder testing machine gyratory compactor
-
asphalt laboratory spacimen compaction equipment pneumatic/ hydraulic roller compactor
-
asphalt laboratory spacimen compaction equipment roller compactor
-
bitumen needle penetration test device, automatic asphalt penetrometer, asphalt penetration apparatus
-
Water in Bitumen and Bituminous materials test set
Product Details
| Brand Name | CE-TECH | Place of Origin | Hebei, China | |
| Model Number | EL42-5305/01 | Power | Electronic |
Product Description
Los Angeles Abrasion Testing Machine
The Los Angeles Abrasion Testing Machine consists of a rolled steel drum having an inside diameter of 711 mm and internal length 508 mm. The drum is rotated by a speed reducer driven by an electric motor at a speed of between 31 and 33 r.p.m. The machine is equipped with an automatic counter, which can be preset to the required number of revolutions of the drum. The unit is supplied without the abrasive charge, which has to be ordered separately depending on the standard in use.
| Internal dimension | 710mm*510mm(±5mm) |
| Rotate speed: | 30-33 r.p.m |
| Outside dimension: | 1100×780×1000mm |
| Abrasive charges: | Set of 12 abrasive charges: 1.13/16” (7 pcs) and 1.7/8” (5 pcs). (ASTM , C.N.R) Abrasive charges(options) Set of 12 abrasive charges: 1.7/8” (EN ) |
| Power: | AC380V 50HZ |
Advantages:
Supplied with an automatic digital counter that shows the number of revolutions for the drum
Provided with a cover and a safety stop button is prominently positioned.
The machine is fitted with a revolution counter and steel tray for specimen unloading.
Supplied with 2sets abrasive charges meet ASTM and EN standard.
One set of 12 abrasive charges: 1.13/16” (7 pcs) and 1.7/8” (5 pcs) (ASTM, C.N.R),
One set of 12 abrasive charges: 1.7/8” (EN)
