Model 16-T0012/P Pneumatic driven dynamic cone penetrometer FEATURES:
Pneumatic DPL and DPM testing set is suitable for doing light (10 kg) and medium-heavy (30 kg) dynamic
penetration tests according to ISO 22476-2 (replaces DIN 4094-3).
This pneumatic DPL and DPM testing set is a cost effective, simple and reliable tool suitable for light dynamic
penetration testing up to approx. 10 - 12 m depth. It comprises of a pneumatic power-pack with a four stroke
gasoline engine and maintenance-free air-compressor all integrated in a sturdy framework with carrying
handle and a solid hammering unit with integrated air-cylinder. The unit holds a 10 kg (and an additional 20
kg) drop-weight, falling height 50cm and a fully automated pressure release valve. The air is led through the
tubes of the framework where it can loose most of its warmth.
The bottom part of the hammering unit is in fact an anvil on which the drop-weight will fall. It is provided with a
holder for the connection piece that goes on to the upper sounding tube.
