UCS TEST 30kn Soil strain controlled triaxial testing machine
Application
TSZ30-2.0 Strain Controlled Triaxial Test Apparatus (hereinafter called triaxial machine) is applied to determine the strength, deformation and pore water pressure of soil sample. According to the different drainage conditions, it can conduct Unconsolidated-Undrained (UU) test, Consolidated-Undrained (CU) test and Consolidated-Drained (CD) test.
Specifications
Model TSZ30-2.0
Sample dimension: dia.39.1×80 mm, dia.61.8×125 mm
Max load: 30Kn
Strain rate: 0.0024-4.5mm/min.
sixteen-speed mechanical transmission
Table stroke: 0-90mm
Confi ning pressure: 0-1Mpa
Back pressure: 0-0.6Mpa
Hole pressure: 0-1Mpa
Volume change: 0-25ml
Graduation: 0.1ml
Axial displacement: 0-30mm
Power: 220V±10%, 50Hz
Machine dimension: 350 x 300 x 1100 (LxWxH)
Controller Dimension(mm): 500 x 500 x 925 (LxWxH)
Weight: 175 Kg
