(Cross Plate) Shear Test Machine (vane Shear)
US$ 2,450 - 2,450
MOQ: 1 Yard
Key Specifications
Get Latest Price
Brand Name:
C-TECH
Place of Origin:
China
Model Number:
AS-1
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
16-T0012/E AS Standard 9kg SOIL DCP MANUAL DYNAMIC CONE PENETROMETERUS$ 700 - 800MOQ: 1 Set -
ASTM Standard DUAL MASS DYNAMIC CONE PENETROMETER (dcp) for SoilUS$ 1,000 - 1,500MOQ: 1 Set
-
Motorized Standard Penetration Test Apparatus SPTUS$ 1,600 - 2,000MOQ: 1 Set
-
ASTM Standard DYNAMIC CONE PENETROMETER TRL DCPUS$ 350 - 350MOQ: 1 Set
-
Sample Reduction Ceramic Mortar and Pestle to Crush Individual ParticlesUS$ 0.5 - 15MOQ: 1 Piece
Brand Name
C-TECH
Place of Origin
China
Model Number
AS-1
Product Description
(Cross plate) shear test machine (vane shear)
AS-1 (Cross plate) shear test machine is used for in situ determining the natural shearing strength of saturated soft clay.
Features
For the high sensitive soft clay, the disturbance when soil sampling and specimen preparation has obvious influence on the strength. This machine has the advantage to determine the strength index that nearer to the actual strength. And as this machine determines the strength index in the borehole, should be used with the drlling equipment, generally can detect 30 m.
Specifications:
Cross board dimension: |
75*150 mm, 50*100 mm |
Steel ring torsion: |
80N.m |
Torsion accuracy: |
0.55N.m |
Guide rod: |
30 * 1040mm |
Dimension(mm): |
430 *910 * 220 (LxWxH) |
Weight: |
40 Kg |
