Product Details
| Brand Name | C-TECH | Place of Origin | Hebei, China | |
| Model Number | ZQB-4 |
Product Description
Light weight and prtable direct shear test machine
Direct Shear Test Machine is used to determine the shearing strength of soil. Generally four specimens are applied to shear stress at different vertical pressure to obtain the shear stress when it is broken. And determine the shear strength, internal frictional angle and cohesive force according to Coulomb’s Law.
Main Technical Parameter
Performance Model No. | ZQB-4 | Remark |
Max. vertical load (KPa) | 400 |
|
Pressure level (KPa) | 50, 100, 200, 300, 400 |
|
Corresponding weights’ weight (kg) | 1.275, 2.55, 5.1, 7.65, 10.2 | Hanging scaffold is the first class. |
Lever ratio | 1:12 |
|
Soil sample | 30cm2 height 2cm |
|
Max. Horizontal shear force (KN) | 1.2 |
|
Power type | Manual | Pushing ram move 0.2mm as hand wheel made a circle |
