Concrete compression testing machine
2000kn hydraulic compression machine
Features:
Hydraulic Manual loading.
Used for testing the compressive and flexural strength of cement, concrete and other building materials. It can be carried out in accordance with the corresponding standard as setting loading rate.
LCD screen display strength, loading speed value, can be configured computer display load curve and data acquisition processing, also can be directly printing and storage test result directly.
Suitable for testing 50mm, 100mm, 150mm and 200mm cube samples as well as cylinder samples with 75-160mm diameter and 150-320mm height.
Pressure safety valve, piston limit switch, removable front and rear gates are standard in all models. Upper compression platens have ball seating assembly for movement in all models. All compression platens have a surface hardness of 50 HRC.
| Max load capacity | 2000kn |
| Accuracy class | class one |
| Span of colum | 400mm |
| Compression space: | 360mm |
| Piston stroke | 200mm |
| Size of compression plates | Dia.300mm |
| Dimension (load frame) | 650*560*1500mm |
| Power(kW | 380V(220V optional), 50Hz(60Hz optional),1.8 kW |
| Weight | 1500kg |
