CVT Resonant Booster Exciting Transformer

CVT Resonant Booster Exciting Transformer thumbnail-1
CVT Resonant Booster Exciting Transformer thumbnail-2
CVT Resonant Booster Exciting Transformer thumbnail-3
CVT Resonant Booster Exciting Transformer photo-1
CVT Resonant Booster Exciting Transformer photo-2
CVT Resonant Booster Exciting Transformer photo-3
US$ 2,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
hance
Place of Origin:
Hubei, China
Model Number:
CVT
Contact Supplier Request Quote Chat Now
Wuhan Hance Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
wuhan/shenzhen/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name hance
Place of Origin Hubei, China
Model Number CVT
Product Description



Test Object and Test Requirements:

1)500kV CVT,capacitance is 0.005uF,test frequency is 50Hz,test voltage is 346kV.

2) 220kV CVT, capacitance is 0.01uF, test frequency is 50Hz,test voltage is 152kV.

3) 110kV CVT, capacitance is 0.02uF,test frequency is 50Hz,test voltage is 76kV.



Working Environment:

1.  Temperature:        -15℃~+55℃

2  Relative humidity:  ≤90%(25℃)

3  Frequency:            50Hz±0.5Hz

4.  Altitude:                 ≤1000M;



Main Technical Parameters and Function:

1. Rated capacity:360kVA;

2. Input power supply:380V,frequency is 50Hz;

3. Rated voltage:360kV;

4. Rated current:1A;

5. Working frequency:50Hz;

6. Waveform distortion rate:  output voltage waveform distortion rate≤1%;

7. Working time:Continuous 5min is allowed under rated load,over-voltage 1.1 times is 1 minute;

8. Temperature rise:temperature rise after 5min continuous operation under rated load≤65K;

9. Quality factor:device itself Q≥10(f=50Hz);

10. Measurement accuracy:system effective value is 1.5 Class.



 Parameters:

Excitation transformer JLB-30kVA/7.5/15/30kV/0.4kV         1 Set

a) Rated capacity:30kVA;

b) Input voltage:0-400V,Single phase;

c) Output voltage: 7.5/15/30kV;

d) Structure:Dry type;

e) Weight:about 150kg;

f)  Reference Size:650*620*550mm



CVT Resonant Booster Exciting TransformerCVT Resonant Booster Exciting Transformer





Company Information

     Wuhan Hance Electric Co., Ltd is a professional manufacturer specializing in developing, producing and marketing electricity meters in electricity industry. Our main products include transformer calibration test equipment, measuring equipment, a variety of electrical test equipment, and automatic substations; they are widely used in electricity, water conservancy, oil, railway, mining, chemical, surveying, teaching, electronics, and other industries.



CVT Resonant Booster Exciting Transformer

Factory

CVT Resonant Booster Exciting Transformer

Customer Visiting

CVT Resonant Booster Exciting Transformer

Certifications

CVT Resonant Booster Exciting Transformer

Our Services

      Our company has always insisted on the guideline of “complete adjustment and 100% inspection”, to enture all devices are fully qualified, as well as a perfect pre-sales services system. The warranty system of “One year warranty and lifetime services” can ensure that every user will enjoy our best service.





FAQ

1. Q: Are you a factory or trading company?

   A: We are a factory been in this area for more than 10 years.

2. Q: How long is the delivery time?

   A: The common device is about one week for in stock, two weeks for out of stock.

3. Q: How long is the warranty period?

   A: We provide one year warranty, life-long maintenance, 24 Hours online service.

4. Q: Can your equipment be debugged abroad?

   A:Of course, we go abroad to debug many times.

5. Q: What is the language about the software?

   A: English or according to your requirement.

6. Q:What is the payment and transaction mode?

   A: Payment is T/T, L/C, D/A,D/P and Trade Assurance. transaction is FOB, CIF, EXW, etc.
