This series of console is suitable for adjustable voltage control of 5-20kVA test transformer.
Working Principle:
Output voltage though adjusting coupling transformer, so as to achieve test transformer rated voltage range adjustment. The console is provided with a high-pressure output voltage meter. Low voltage output current meter, can read the voltage value conveniently, though over-current protection circuit, reliable protection equipment, designed timing alarm circuit, make the test be more convenient. Proved by user, its principle is simple, structure is compact, work is reliable, easy to use, is the ideal equipment for high voltage test.
Parameters:
a) Rated Output Capacity: 30kVA
b) Working Power Supply:380±10%V Power Frequency
c) Output voltage:0 - 400V
d) Rated input current:75A
e) Rated output current:75A
f) Running time:continuous 5min is allowed under rated capacity
g) Components maximum temperature ≤65K
h) Noise level:≤50dB
i)Weight:about 80kg
j) Size:600*450*800MM
Wuhan Hance Electric Co., Ltd is a professional manufacturer specializing in developing, producing and marketing electricity meters in electricity industry. Our main products include transformer calibration test equipment, measuring equipment, a variety of electrical test equipment, and automatic substations; they are widely used in electricity, water conservancy, oil, railway, mining, chemical, surveying, teaching, electronics, and other industries.
Our company has always insisted on the guideline of “complete adjustment and 100% inspection”, to enture all devices are fully qualified, as well as a perfect pre-sales services system. The warranty system of “One year warranty and lifetime services” can ensure that every user will enjoy our best service.
1. Q: Are you a factory or trading company?
A: We are a factory been in this area for more than 10 years.
2. Q: How long is the delivery time?
A: The common device is about one week for in stock, two weeks for out of stock.
3. Q: How long is the warranty period?
A: We provide one year warranty, life-long maintenance, 24 Hours online service.
4. Q: Can your equipment be debugged abroad?
A:Of course, we go abroad to debug many times.
5. Q: What is the language about the software?
A: English or according to your requirement.
6. Q:What is the payment and transaction mode?
A: Payment is T/T, L/C, D/A,D/P and Trade Assurance. transaction is FOB, CIF, EXW, etc.
