DTS200 Common Rail Diesel Injector Test Bench With Piezo

DTS200 test bench is our latest independent researched special device to test the performance of high-pressure common

rail injector, controlled by industrial computer, Windows operating system. The oil quantity is measured by sensor and

displayed on computer screen (Electronic fuel delivery system). All data can be searched and saved. It adopt Servo

motor can works with light voltage. The rail pressure can be adjusted automatically, and it also provide pressure

overload protect. It can test common rail injector of BOSCH, SIEMENS, DELPHI, DENSO. Advanced technology,

steady performance, precise measurement and convenient operation.

>>>CHARACTERISTIC

1. Controlled by industrial computer in real time, Windows operating system.

2. Oil quantity is measured by sensor and displayed on 10.4'' tactile LCD screen;

3. More than 400 kinds of injectors data can be searched and used.

4. Pulse and frequency of the injector can be adjusted.

5. Injection time can be set .

6.Protection function of short-circuit.

7.Precise measurement, easy operation, low noise.

>>>FUNCTION

1.Test injector brands:BOSCH, SIEMENS, DELPHI, DENSO.

2. Test 1 piece of injector.

3. Test the pre-injection of common rail injector.

4. Test the max. oil quantity of common rail injector.

5. Test the cranking oil quantity of common rail injector.

6. Test the back flow oil quantity of common rail injector.

7. Test the average oil quantity of common rail injector.

8. Test the seal performance of common rail injector.

9. Data can be searched and saved.

>>>TECHNICAL PARAMETER

1. Pulse width: 0.1~20ms

2. Continuous injection times: 0~1000

3. Fuel temperature: 40±2℃

4. Rail high pressure: 0~1600 bar

EPS200 MANUAL

3

NANTAI

5. Test oil filtered precision: 5μ

6. Input power: AC 220V

7. Rotation speed: 0~3000RPM

8. Oil tank capacity:6L

9. Weight:150KG.
