Common Rail Injector Test Bench EUS800 With Cater HEUI Testing

CAT8000 common rail injector test bench, use Germany  import the flow sensor for the measurement means, it can test common rail  injector  and common rail pump, it can add HEUI function, can test HEUI, and with Bosch IQA Coding function, IQA self-definition and injection adjustment according to the real working condition instead of repairing the complete injector.

The device uses high-power inverter and motor, heavy plate casting table for different power and torque of the common rail pump test. It can test Bosch, Denso, Delphi, Siemens, CAT  and other brands of electronic control fuel injector, oil flow measurement using imported flow sensor. Measurement parameters, rail pressure, speed, temperature, fuel, computer display. .

The test bench has independent diesel active oil supply system, the pressure size can be adjusted with different adapters, can increase HEUI test.

Technical Parameters

Applicable for HEUI injector, All CR injectors ,Piezo injector ,All HEUI injector

-- CP3.3 common rail pump

--original common rail +DRV

--Common rail system motor Power 5.5KW

--HEUI drive power:3KW

--Oil system pressure automatic adjustment system

--Diesel tank (heating, cooling, liquid level, temperature sensor, temperature security)

--Oil tank (heating, cooling, liquid level, temperature sensor)

--Industrial PC (with touch screen, built-in WIFI remote training, service, upgrade)

--Flow meter (German ZDM) injector flow sensor

--Flow meter (German KRACHT) oil flow sensor

--Drive circuit board(solenoid valve electric parameters: to enhance the voltage, current, time, pull in voltage, current, time, keep voltage, current, time, according to the setting of the parameters of production factory
