BC-CR318 HEUI Common Rail Injector Test Bench for Testing the Heui Injectors and cr Injectors

The popular automobile BC-CR318 HEUI common rail injector tester

Testing range

• Bosch IQAcoding

• With all functions of CR300 and CR305
• inbuilt with reliable actuated pump
• oil pressure flexible adjustment through automatic or manual ways
• Oil flow-back self testing
• Oil actuating response time testing
• Fuel injection response time testing
• Solenoid resistance & inductance testing
• Solenoid pull-up time testing
• Dynamic condition internal leakage testing

 Notes:  options

 Applicale for HEUI injector,All CR injectors ,Piezo injector ,All HEUI injector

 --BOSCH CP3.3 common rail pump

 --BOSCH original common rail +DRV

 --Common rail system motor Power 5.5KW

 --HEUI drive power:3KW

 --Oil system pressure automatic adjustment system

 --Diesel tan)heating,cooling,liquid level,temperature sensor,temperature security)

 --Oil tank(heating,cooling,liquid level,temperature sensor)

 --Industrial PC(with touch screen,built-in WIFI remote training,service,upgrade)

 --Flow meter(German ZDM) injector flow sensor

 --Flow meter(German KRACHT) oil flow sensor

 --Drive circult board(solenoid valve electric parameters:to enhance the voltage,current,time,pull in

 voltage,current,time,keep voltage,current,time,according to the setting of the parameters of

 production factory

 Function:

 Test of all the manufacturers of common rail injector

 Test all of the manufacturers of piezo injectors

 Test CAT HEUI (Oil common rail) injector

 Test all of the common rail pump with ZME*

 Test DENSO HP0 pump*

 Test CAT 320D common rail pump*

 Test EUI EUP*

 The function with * means it will also need a mechanical test bench so these function can work.

 Test CAT HEUI enginer oil pump*

 Leak testing

  1,Oil static condition leakage testing

  2,Fuel static condition leakage testing

  3,Oil flow-back under dynamic condition testing

 Injection testing

  1,VL testing (Max injection)

  2,TL testing (Middle speed)

  3,LL testing (Idle speed)

  4,VE testing (Pre-injection)

  5,Starting testing

  6,Oil flow-back under dynamic condition testing
