Middle Pressure HEUI&High Pressure Common Rail Diesel Fuel Injector Testing Bench

CAT8000 common rail injector test bench, use Germany  import the flow sensor for the measurement means, it can test common rail  injector  and common rail pump, it can add HEUI function, can test HEUI, and with Bosch IQA Coding function, IQA self-definition and injection adjustment according to the real working condition instead of repairing the complete injector.

The device uses high-power inverter and motor, heavy plate casting table for different power and torque of the common rail pump test. It can test Bosch, Denso, Delphi, Siemens, CAT  and other brands of electronic control fuel injector, oil flow measurement using imported flow sensor. Measurement parameters, rail pressure, speed, temperature, fuel, computer display. .

The test bench has independent diesel active oil supply system, the pressure size can be adjusted with different adapters, can increase HEUI test.

Technical Parameters

Applicable for HEUI injector, All CR injectors ,Piezo injector ,All HEUI injector

--BOSCH CP3.3 common rail pump

--BOSCH original common rail +DRV

--Common rail system motor Power 5.5KW

--HEUI drive power:3KW

--Oil system pressure automatic adjustment system

--Diesel tank (heating, cooling, liquid level, temperature sensor, temperature security)

--Oil tank (heating, cooling, liquid level, temperature sensor)

--Industrial PC (with touch screen, built-in WIFI remote training, service, upgrade)

--Flow meter (German ZDM) injector flow sensor

--Flow meter (German KRACHT) oil flow sensor

--Drive circuit board(solenoid valve electric parameters: to enhance the voltage, current, time, pull in voltage, current, time, keep voltage, current, time, according to the setting of the parameters of production factory

Performance Introduction:

Bosch IQA coding

IQA self-definition and injection adjustment according to the real working condition instead of repairing the complete injector.

Oil temperature not higher than 42 degree under 24 hours non-stop running

High reliability with zero failure under the whole-year normal operation

Very good injection testing accuracy

Very good repeated testing consistency

Very low operation noise

Inbuilt with reliable actuated pump

Oil pressure flexible adjustment through automatic or manual ways

Solenoid pull-up time testing

Dynamic condition internal leakage testing

Optional function:

Injector responding time testing

Injector resistance & inductance testing

Injector AHE & life testing

The rail pressure can reach to 2400bar

Oil flow-back self testing

Oil actuating response time testing

Fuel injection response time testing

Solenoid resistance & inductance testing

Main products include:
     1, Diesel engine parts (nozzle, plunger, delivery valve, head Rotor, injector, fuel pump and other accessories) 2,  Injection pump test bench 3,auto tools 4  Auto parts 5, special vehicles 6 , Turbocharger.......
     Production process using advanced computer control and digital display systems, production technology, strong technical force . High quality, high technical performance, with micro-controller and digital functions. Products are sold  more than 100 countries and regions of all world .
