Help CenterCR825 Multifunction Test Bench, General Injection Pump, Common Rail , EUI/EUP, HEUI , VP37 ,RED4,VP44 PUMPS
Related Products
-
12PSB DIESEL INJECTION PUMP TEST BENCH 380V 3PHASEUS$ 2,800 - 2,800MOQ: 1 Piece -
DTS619 DIESEL INJECTION PUMP TEST BENCH 380V 3PHASEUS$ 3,600 - 3,600MOQ: 1 Piece
-
Multifunction Test Bench CR825 Common Rail Test Bench HEUI and EUI EUP TESTING INLINE PUMP TESTUS$ 12,500 - 17,000MOQ: 1 Piece
-
The New Design 2019 Popular CR825 Multifunctional Pump Test BenchUS$ 16,000 - 17,000MOQ: 1 Piece
-
Diesel Pump Calibration Machine CR825 Common Rail Diesel Injector Pump Calibration Test BenchUS$ 16,000 - 17,000MOQ: 1 Piece
Ø Function:
1, All common rail injector (include piezo )
2,All common rail pumps
3,Denso HP0 PUMP testing
4,EUI/EUP testing
5,HEUI injector testing
6,HEUI pump testing
7,CAT 320D pump testing
8,Electronic pump testing
9,Measurement unit testing
10,Armature stroke AHE test
Ø Optinal Function:
1,VP37/VE37 electronic pump
2, Vp44 pump test
3, TICS electronic pump
4, Electronic unit pump
5, General pump test(E2 pump)
Main power |
380V AC 220V AC(Optional) |
|
Phase |
Three single(optional) |
|
Frequncy |
50Hz/60Hz |
|
Current |
45A(MAX) |
|
Mian motor |
22KW |
|
Main motor rotation |
0-4000 RPM/MIN |
|
Oil motor HP/ Flow |
0.19KW / 13L/MIN |
|
Diesel motor HP /Flow |
0.19KW / 13L/MIN |
|
Control circuit voltage |
DC12V/24V 350W |
|
ECU internal voltage |
0-200V DC(MAX) |
|
Oil tank volume |
30L |
|
Diesel Tank volume |
52L |
|
Temperature control |
Heating/Forced cooling |
|
Max rail pressure |
180MPa 240MPa(Optional) |
|
Flowmeter(injection) |
4—550ml/min |
|
Flowmeter(fuel supplying) |
1—400L/H |
|
Flowmeter(fuel flow back) |
1—400L/H |
|
Flowmeter(Oil) |
5—600L/H |
|
Center distance between motor and working bench |
125mm |
|
Weight |
1100KG |
|
Outlook size net |
(LXWXH)2250X1260X1920 |
|
Wooden cage |
(LXWXH)2350X1500X2100 |
|
