Help CenterNT3000 12 Cylinders Diesel Used Fuel Injection Pump Test Bench
Related Products
-
Diesel Fuel Injection Pump Test Bench NT3000US$ 3,900 - 5,300MOQ: 1 Piece -
DTS619 Equivalent Diesel Injection Pump Calibration MachineUS$ 2,700 - 8,000MOQ: 1 Piece
-
CRS708 Common Rail Injector Simulator /test BenchUS$ 5,000 - 5,700MOQ: 1 Piece
-
EPS 815 Pump Test Bench Diesel Injection Test Bench 380v 3phase or 220v 2phaseUS$ 3,700 - 8,000MOQ: 1 Piece
-
Cdi 3000 Multi Cr3000a Common Rail Test BenchUS$ 4,800 - 5,700MOQ: 1 Piece
>>> Introduction:
DTS619 adopt industrial pc with color CRT, It’s the newly researched production for the direction of
high power and safety to the environment. It has human-machine interface, digital controlling of
rpm, temperature, pressure, diesel fuel pump technical parameter and so on, and in pace with print. It
easy and quick operates ,it’s really human-machine dialog. This series test bench adopt high quality
frequency conversing device and cast iron base supper size bed, and its distinguishing features are
hi-stable character, hi-reliability, ultra-low-noise, perfect auto-protecting function and so on, It is
advanced products.
>>> Main function:
1.Measurement of each cylinder delivery at any speed.
2. Test point and interval angle of oil supply of injection pump.
3. Checking and adjust the mechanical governor.
4. Checking and adjusting the distributor pump.
5.Experiment and adjusting of behavior of supercharging and compensatory device.
6. Measurement of oil return of distributing pump
7. Testing of the electromagnetic valve of distributor pump.(12V/24V)
8. Measurement of the internal pressure of distributor pump.
9. Checking of the advance angle of advance device.(on request)
10. Checking the sealing of injection pump body
11. Install tube of auto-sucking oil supply can check on oil supply pump(including VE pump.)
12. Checking the travel of stroke
13. Oil lubricate(on request)
14.Cast iron base(on request)
15. Foced cooller(on request)
16. Two operating systems(Computer control + Digital control)
17. LCD touch screen (on request)
Adjustable | Out | RPM | Rpm pre-set | Temperature | Positive | Positive |
| 12 | 7.5 | 0-4000 | √ | √ | √ | √ |
| Air supply | DC power | internal | Oil return of | travel of tooth | Advanced | Capability with |
| √ | √ | √ | √ | √ | √ (On request) | All in- line and |
>>> Main products include:
1, Diesel engine parts (nozzle, plunger, delivery valve, head Rotor, injector, fuel pump and other accessories) 2, Injection pump test bench 3,auto tools 4 Auto parts 5, special vehicles 6 , Turbocharger.......
Production process using advanced computer control and digital display systems, production technology, strong technical force . High quality, high technical performance, with micro-controller and digital functions. Products are sold more than 100 countries and regions of all world .
