Flatbed Cutting Plotter Speed Creaser Garment Cutter 1510B3 Type

FOB Price

USD $2385 - $2785 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Shanghai or Any Other China Port
Payment Terms:T/T Credit Card Other Cash Escrow
Delivery Detail:3 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	KAEMI or GM	Place of Origin:	China	Model Number:	GM1510B3
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

 Flatbed Cutting Plotter Speed Creaser Garment Cutter 1510B3 Type

Specification

Model	GM-1209B3	GM-1509B3	GM-1510B3	GM-1512B3
Cutting Window(Fabric Scope)	1200*900mm	1500*900mm	1500*1000mm	1500*1200mm
Overall Dimension(mm)	16001280750	19001280750	19001380800	19001580800
Cutting Speed	1200mm/s
Cutting Thickness	2mm
Cutting Materials	White Paper, Kraft, Plastic Board, Fiberboard, etc
Repeatability Precision	≤0.01mm
Communication Port	USB/RJ45 Ethernet; Shared Folder Print in LAN
Buffer Memory Size	1M/8M/32M(Can butter more than 1 page)
File Formats	HPGL(Compatible with Domestic and Interntional CAD Online)
Control Panel	9 Keys and LED Display
Motor/Driver	High Performance 3 Phrase Step-motor
Supply Voltage	AC 220V/110V±10%, 50Hz/3.5KW
Working Environment	Temperature:-30~50℃ or -22~122℉; Humidity: 10%--95% RH
Fasten	Vacuum Adsorption
Paper Thickness	150g-500g/㎡
Application Areas	Garment, Shoes-Making, Bags, Furniture, Automobile Decoration, Box Cutting, etc

Product Description

Main Features

1. New Frame Design Ensures Machine Stablility When Runs at High Speed 2. Optimized Circuit Layout; More Compact Electrical; Better Heat Dissipation; More Reasonable 3. Cutting Starting Points and Cutting Sequence Display System 4. System Updated to the Latest Version. Optimized Dashed Lines, Arcs, Machines Runs More Smoothly 5. Unique Error Data Identification Function

Company Profile

Wuhan Gemei Joint Technology Co., Ltd.

 is located in the national economic development Zone - Wuhan Linkong economic development zone in the beautiful River City. It is a specialized company specializing in the research and development, production, sales and service of automation equipment for the industries of clothing,bags and shoes. The company shoulders the historical mission of "changing traditional industries with high technology", and is committed to providing CAM / CAD integrated solutions for garment,luggage,footwear and other enterprises. Gemei is also a high-tech enterprise and a software enterprise in Hubei Province, an "information port" certification enterprise and an entrepreneurship enterprise for overseas students in Wuhan City.

Since its establishment, GEMEI has developed a series of cutting machines for clothing, bags, shoes and hats, and obtained a number of software copyright and patent certificates. Based on the profound understanding of China’s garment, luggage and footwear industry, GM series of cutting machine combines the essence of Chinese and foreign technologies, closely combines the advantages of the world's advanced technology and Chinese manufacturing industry, adopts a novel design different from the domestic traditional cutting machine, and fully experiences the design principle of "good at core, simple in shape". After the first continuous drum cutter came into being in the middle part of China , we successively developed the sample cutter for the luggage industry and continuous cutting garment sample cutter. "The competition of enterprises is the competition of talents." GEMEI firmly grasps the trend that the world manufacturing industry is transferring to the middle part of the world, and has established a research and development team composed of doctors and senior engineers and other high-quality talents,and insists that "innovation" is the eternal power of the development of GEMEI.

Packing & Delivery

Exhibition

Certifications

FAQ

1. Q: Are you a manufacturer? A: Yes, we are specializing in the r&d production for template cutter/inkjet cutter/pen writing cutter/cnc digital fabric cutter/graph plotter in this field for 10 years. 2. Q: How do you pack these products? A: Usually packed in wooden case and can pack according to export standard or your requirement. 3. Q: Is it customizable? A: Yes, We have basic sizes commonly applied in the field and can customize according to your requirements. 4.Q: After-sales service A: Yes, professional after-sales team and 24-hour technical support by phone, email or skype 5.Q: What is your lead time? A: Spot goods usually take 2-4 days, and customization takes 5-7 days
