Help CenterTBT-6210 Multi Functional Digital Display Automatic Surface Roughness Tester
Related Products
-
ES Quartz Glass Popular Q-80 Self Mashing Continuous Flowthrough CellUS$ 10 - 50MOQ: 1 Unit -
IR Quartz Glass Economic Q-73 Self Mashing Continuous Flowthrough CellUS$ 10 - 50MOQ: 1 Unit
-
Flow Into Funnel Good Quality Bulk Density TesterUS$ 200 - 700MOQ: 1 Set
-
Pin Type 0-80% Moisture MeterUS$ 100 - 200MOQ: 1 Set
-
Large Path Length Standard Cell With StopperUS$ 30 - 50MOQ: 1 Unit
Surface Roughness Tester
* Be compatible with four standards of ISO, DIN, ANSI and JIS.
* Multiple parameter measurement: Ra, Rz, Rq, Rt.
* Highly sophisticated inductance sensor.
* Four wave filtering methods : RC, PC-RC, GAUSS and D-P.
* Built-in lithium ion rechargeable battery and control circuit with high capacity.
* Small in size, light in weight and easy to use.
* Manual or automatic shut down.
* Can memorize 7 groups of measurement results and measuring conditions for later use or download to PC.
* Metric /Imperial Conversion.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
|
Standards |
GB/T6062,ISO4287,DIN4768,JIS B,ANSI46.1 |
|
|
Parameters |
Ra,Rq,Rz,Rt |
|
|
Measuring Range |
Ra,Rq:0.005~16.00µm Rz,Rt:0.020~160.0µm /0.020~629.9µinch /0.078~6299µinch |
|
|
Accuracy |
<<±10% |
|
|
Fluctuation of Display Value |
<<6% |
|
|
Resolution |
0.001/0.01/0.1 |
|
|
Sensor |
Radius of Probe Pin |
5µm |
|
Material of Probe Pin |
Diamond |
|
|
Measurement Force of Probe |
4mN(0.4gf) |
|
|
Probe Angle |
90º |
|
|
Vertical Radius of Guiding Head |
48 mm |
|
|
Maximum Driving Stroke |
17.5mm/0.7inch |
|
|
Cutoff length(l) |
0.25mm,0.8mm,2.5mm |
|
|
Driving Speed |
Sampling |
When Length=0.25mm,Vt=0.135 mm/s |
|
When Length=0.8mm,Vt=0.5mm/s |
||
|
When Length=2.5mm,Vt=1mm/s |
||
|
Returning |
Vt=1mm/s |
|
|
Profile Digital Filter |
RC,PC-RC,GAUSS,D-P |
|
|
Evaluation Length |
1~5L Optional |
|
|
Data Memorize |
7 Groups |
|
|
Operating Conditions |
Temp:0~50ºC Humidity:<80%RH |
|
|
Power Supply |
Bulit-in Rechargeable Li-ion Battery |
|
|
Dimensioms |
140x52x48mm |
|
|
Weight |
420g |
|
|
Standard Accessories |
Main Unit |
|
|
Standard Sample Plate SSP-100 |
||
|
Standard Sensor SSP-100 |
||
|
Small Screwdriver |
||
|
Power Adapter |
||
|
Carrying Case ( B09 ) |
||
|
Operation Manual |
||
