TBTTM-8170D2 Ruuber plastic other polymer Programmable LCD Double Vulcanizing Machine
1. DESCRIPTION:
This machine applies to the compression and moulding of rubber, plastics, resins and other polymer materials. It's equipped with a programmable LCD, which can set pressure, temperature, time, exhausting frequency and the number of seconds with human-machine interface operating system. The vulvanization process will be dynamic cally and instantly displayed and monitored. The mould pressing process will be completed automatically. This machine is very simple with extensive and efficient application.
2. MAIN SPECIFICATION:
|
Capacity |
100T |
|
Temperature |
Room temperature to 300℃ |
|
Temperature accuracy |
2℃ |
|
Heating method |
Electrical Heating Module |
|
Heating-up time |
Room temperature - 200℃, 35mins |
|
Pressure Plate |
400*400/450*450/500*500mm |
|
Cold Pressure Plate |
300-550mm |
|
Distance of Pressure Plate |
150-300mm |
|
Pressure Material |
SKD chromium-molybdenum alloy |
|
Pressure Surface |
Mirror chrome plate |
|
Vulcanizing time |
0-999, 3 sections |
|
Oil cylinder speed |
11-50mm/s |
|
Power supply |
AC380V,3phase |
