Cleveland Open Flash Point Tester/flash point testing equipment/petroleum test apparatus
TBT-3536-1
1. It adopts technology of single chip microcomputer and LCD screen. English man-machine interface. The heating device is continuously adjustable. Easy to set parameters.
2. The LCD screen has prompt menu, prompt type input for operation interface. It shows set parameters and real-time display sample temperature and other parameters. Press the record key when flash point appearing. The screen will display and save flash point value.
3. It is newly design and small structure. Stainless steel working table make it elegant and beautiful. The operator can do determination as long as connecting with coal gas or other civil gas. Easy to use and results are exact.
4. It is equipped with wind-shelter and flame extinguishing cover which are accord with requirements of test.
Accurate heating rate.The instrument can do test automatically.
5. Operator only need to observe the flash point appearing. The cost performance is high.
Power supply |
AC(220±10%)V, 50Hz. |
Heating device |
Electric furnace heating, no naked fire, explosion prevented.The power is adjustable from 0W to 600W. The max heating temperature can reach 400℃. |
Temperature control |
Single chip microcomputer.The heating rate can meet requirements of standards GB/T 3536-2008 and ASTM D92. |
Temperature display |
LCD shows temperature parameters. The display range is 0℃~400℃, display accuracy is 0.1℃. |
Flash point detecting device: |
It applies the test flame automatically. |
Temperature sensor: |
RTD, PT100 |
Igniting device |
(1) Ignition source: coal gas (or civil gas) (2) Flame diameter is 3.2mm~4.8mm |
Ambient temperature |
(-10∼50)℃ |
Relative humidity |
≤85% |
Maximum power consumption |
650W |
Dimension: |
340mm×320mm×450mm (Temperature sensor is included) |
Package
---Carton box, wooden case or specified package
1) Inner package: dust-proof plastic bag
2) Outer package: standard export wooden case with pallet
3) Suitable for international transport through shipping by sea, by air or any other delivery method.
(Note: we can provide special packages according to buyer’s requirements.)
Delivery time
---within 2weeks after payment, we will act fast and before shipment, we will provide product photo, packing photo to customer’s checking
Shipping method
---Express: UPS, FEDEX, DHL, TNT, EMS, etc
---Air shipping: Please choose your convenient shipping method according your detail requirement.
---Sea shipping: large quantity order
---Normally, it will take around 3--5days from China to destination country via air.
Payment
---T/T, Western Union, Paypal, or negotiable, ect.
How to oder products?
---Send inquiry to us or contact with us via skype or trademanager
---Confirming the model, specification, price, qty, delivery time and payment method
---Sending invoice to customer
---Customer makes payment and send us receipt
---Arranging production
---Sending products picture to customer after the production is ready
---Shipping products to customer
Warranty
---1 year quality assurance
