Lab Single Horizontal Axles Forced Concrete Mixer For Sale
- 50 Set / Sets per Month
- any port in china/Concrete Mixer
- T/T Credit Card
- Testing Water Base Drilling Fluids ASTM Mud Balance
- Sand Content Test Kit With 3-pieces Suits
- 1 Liter Volume Mortar Air Entrainment Meters
- Direct Reading Air Entrainment Meter For Mortar
- Los Angeles Abrasion Machine/Civil Laboratory Equipment/Abrasion Resistance Tester for sale
- 150mm One Gang Lab Mortar Casting Iron Cube Test Molds Casting Iron testing mould
Product Details
Brand Name: | OBRK | Place of Origin: | Hebei, China | ||
Outline Dimension: | 1520 x 530 x1060 mm, 1520 x 530 x1060 mm | Discharge Way: | Automatic, Automatic | ||
Working Cycle Period: | 45m | Water Supply Mode: | Mannual, Mannual | Speed of Mixing Drum: | 45r/min |
Reclaiming capacity: | 30 | Charging Capacity: | 48 | Mixing Power: | 1.5KW |
Motor Power: | 1.5KW |
Product Description
Lab Single Horizontal Axles Forced Concrete Mixer For Sale
Product Specification
Feeding capacity | 96 liters |
aken the discharging capacity | 60 Litres |
Taken the maximum discharge capacity | 66 liters |
Taken the mix time | 45 seconds or less |
Taken the stirring shaft speed | 48 Z/m |
Taken the power supply voltage | 380 v - 1.5kw |
shape size | 1520×530×1060mm |
Weight Appx | 200kg |
Detailed Features And Design
- It can mix ordinary concrete and dry hard concrete, and can also be used for mixing different materials in laboratories of other industries.
Usage of Laboratory Concrete Mixer
- Adjust the timing of the mixer according to the mixing time, and pay attention to the need to adjust when the power is cut off.
- When the button is pressed, the spindle drives the mixing shovel to run. Stop automatically after the set time is reached.
- When discharging, stop the machine first, open the lock pin, move the handle to rotate the barrel to a fixed position, and then locate the spindle with the lock pin, so that the mixture is discharged out of the barrel.
- HJW-30/60 type forced single horizontal axis concrete mixer is suitable for laboratories of construction research institutes, construction companies and concrete component units.
- The machine has the advantages of simple operation, high mixing efficiency, small residue and convenient cleaning. It is an ideal laboratory concrete mixing equipment.
- Structure: The machine is composed of frame, mixing device, transmission system and electrical control system.
Detail for Lab concrete mixer
- The frame is the supporting part of the whole equipment, which is composed of channel steel welding.
- The stirring device consists of a post stirring cylinder, a stirring shaft and a stirring shovel.
- The stirring shovel is fixed on the stirring arm and is integrated with the stirring arm to form two groups of spiral band stirring shovels with the same spiral direction, lead and spiral angle.
- The gap between the stirring shovel and the inner wall of the stirring drum can be adjusted slightly.
Our Service
- Installation and training
- If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.
- Without visiting, we will send you user manual and video to teach you to install and operate.
- If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
- After Service
- One year guarantee for whole machine.
- 24 hours technical support by email or calling
- If there is any problem found of the machine, we will repair it for free in one year.
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
We can provide high quality products. OEM or OEM orders are also welcome.
Note: The company can customize mixers of various specifications according to the needs of customers
Why Choose OBRK?
- Oubeiruike supply verious type of products,Test Molds, Concrete Mixer,Asphalt Tester,and Soil Road Lab Tester .... We assure high quality to you.
- All our products are made in China and with competitive price.Excellent quality with competitive price.We can offer OEM & ODM service.
Certificate
Packaging And Shipping
- Packaging Details Deval Abrasion Testing Machine is standard export wooden case.
- Port any port in china/Deval Abrasion Testing Machine
- We can deliver by sea at any port in china, and Also can ship by air via express company (door to door),it is quick and safe.
- We can ship By EMS,TNT,DHL and others ( door to door)
FAQ
Q:Are you trade company or factory?
A:We are trade company but we also have own factories. Building trade company is just for exporting various types of concrete mould and others products.
Q:Why your price is higher than others?
A:As we persist on that each factory should put quality at the first place. We spend time and money on developing how to make machines much more automatic, accurate and high quality. We can make sure that our machine could use more than ten years without any problem. We can provide one years free quality assurance.
Q:How to visit your company?
A:1. Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can pick up you.
2.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick you up.
All our products will be inspected thoroughly before shipping.Hope you will enjoy this shopping journey and we hope to have a long-time relationship with you. Welcome to visit our factory! Any questions please contact us, we will be of your service
