Testing Equipment concrete rebar scanner/finder/locator/detector PQI-023

Name: Testing Equipment concrete rebar scanner/finder/locator/detector PQI-023
Brand: OBRK
Price: USD $2,200 - 2,300 / Set

FOB Price

USD $2,200 - $2,300 / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

OBRK

Place of Origin:

Hebei, China

Model Number:

PQI-023

Product Description

testing Equipment concrete rebar scanner/finder/locator/detector PQI-023

product description

The instrument is a portable non-destructive testing instrument, which can be used for the detection of the construction quality of reinforced concrete structures. It can measure the position of the steel bars on the concrete surface, detect the thickness of the steel protective layer and the diameter of the steel bars. In addition, the magnetic properties inside the concrete structure can also be The position of the body and the conductor are detected, such as the internal cable of the wall, the plumbing pipe, etc., and the detection before construction can effectively avoid damage to these facilities during construction and reduce accidents.

Technical parameters:

Item name	Digital Metal Scanner Finder Rebar Detector
Rebar diameter setting range	Φ6mm ~ Φ50mm
Small range	2-100mm
Large range	2-200mm
Maximum thickness of protective layer	±1 2-75mm
	±2 76-100mm
	±3 101-130mm
	±4 131-200
Diameter estimation range	6mm-50mm
Diameter indication maximum error	±1 specification
Diameter display accuracy	0.1mm
Screen size	3.2 Inch
Working temperature	-10℃~+40℃
Working humidity	<90%RH
Power supply	Lithium battery
Weight	5Kg
